WOODWARD 9905-973

WOODWARD 9905-973 is a high-performance measurement and control device.The following is a detailed introduction to the device:

1.Basic Overview

WOODWARD 9905-973 equipment is suitable for the measurement and control of large AC currents in various electrical systems,electroplating,and electrolysis industries.It adopts advanced technology and design,and has the characteristics of high precision,high stability and high reliability,and can meet the application requirements in various complex environments.

WOODWARD 9905-973

2.Main Features

No input saturation:Due to the use of the Rogowski principle,the magnetic core that must be used in the traditional mutual inductor principle or Hall principle is abandoned,so that the input range of the product can be very large without affecting the performance.

Fast response time:The response time can reach the microsecond level,which is suitable for fault recording in power systems.

Broad frequency response:The bandwidth range can reach more than 20kHz,which is widely used in signal detection such as complex input waveforms.

Good linearity:The linearity of the output can reach 0.2%,which can accurately reflect the size of the input signal.

High accuracy:The overall accuracy is within 1%,ensuring the accuracy of the measurement.

Small size and light weight:Compared with traditional products based on the mutual inductor principle and the Hall principle,this product is smaller and lighter under the same input range.

III.Main technical indicators

Rated input:0~20kAac

Rated output:0~20mAdc,0~5Vdc,4~20mAdc

Accuracy:1.0 level

Linear range:0~120%

Isolation withstand voltage:5000Vdc/1 minute

Auxiliary power supply:+12Vdc,±12Vdc,+24Vdc

Operating temperature:-20℃+60℃(another saying is-40℃+85℃)

Temperature drift:<300ppm/℃

WOODWARD 9905-973

IV.Product wiring and installation

Product composition:The product is divided into two parts:the sensor head and the integrator.The sensor head and the integrator are connected by a shielded wire.

Wiring instructions:The sensor head input terminal is connected to pins 1 and 2,the sensor head ground terminal is connected to pin 3,the integrator auxiliary power input terminal is connected to pins 7 and 8,the output signal ground terminal is connected to pin 13,the tracking voltage output terminal is connected to pin 14,the DC voltage output terminal is connected to pin 15,and the DC current output terminal is connected to pin 16.

Installation method:The integrator adopts an S-shaped appearance structure and can be installed using a DIN35 rail or screw fixed installation.

V.Application field

WOODWARD 9905-973 equipment is widely used in various electrical systems,electroplating,electrolysis industries,AC large current measurement and control,as well as fault recording in power systems due to its high precision,high stability and high reliability.
