TSXPBY10

TSXPBY10 is a high-performance fiber optic network product.The following is a detailed introduction to it:

1.Product Features

Logically independent dual bus electrical interface:

It can realize the backup of electrical interface or single device access to dual redundant bus system,which improves the reliability and stability of the system.

TSXPBY10

Multi-network topology support:

It can form a variety of fiber optic networks,such as point-to-point network,dual optical port chain network,etc.

In a point-to-point network,two Profibus DP bus segments can be connected by optical fiber.

On the optical fiber bus of the dual optical port chain network,multi-segment Profibus DP bus connection can be realized(up to 200).

Dual fiber ring network redundancy function:

The dual optical port is used to realize the dual fiber ring network redundancy function.When a fiber fails somewhere,the system will rebuild the network link within 10ms to ensure the normal communication of the system.

The self-healing protection function of signal transmission is realized,and the system will automatically recover after the network fault is eliminated.

Proprietary ring network protocol:

The company’s self-developed proprietary ring network protocol Ci-ring is adopted.No settings are required,no root node is required,and the network ring and de-ring functions can be quickly completed.

Plug and Play:

The product is plug and play,no configuration is required,which greatly simplifies the user’s installation and debugging process.

2.Performance indicators

Data electrical interface:

9-pin Sub_D jack connector,the pin definition complies with the protocol specification of Profibus DP.

Support Profibus DP bus standard.

Communication rate:

It can reach 9.6kBit/s to 12MBit/s,providing a variety of rate options to meet different application requirements.

Signal delay:

Electrical port signal delay≤11Bit.

Optical port signal delay≤1.6us/node.

TSXPBY10

Lightning protection and overcurrent protection:

It has 4000V lightning protection,1.5A overcurrent protection and 600W surge protection to ensure the stable operation of the product in different environments.

Fiber parameters:

Fiber wavelength:multimode 850nm,1310nm;single mode 1310nm,1550nm.

Transmission fiber:multimode 50/125um,62.5/125um,100/140um;single mode 8.3/125um,9/125um,10/125um.

Transmission distance:multimode 2Km,single mode 20Km(longer distance optional).

Fiber interface type:SC,FC,ST optional,standard SC optical interface.

III.Application field

TSXPBY10 is widely used in industrial automation,intelligent manufacturing,rail transportation,energy and power and other fields,providing efficient and reliable connection and communication solutions for various complex fiber optic networks.

IV.Product advantages

High reliability:

Redundant design and self-healing protection function are adopted to ensure the stable operation of the system.

High performance:

Support high-speed communication rate and multiple network topologies to meet the needs of complex application scenarios.

Easy installation and debugging:

The product is plug-and-play,which simplifies the installation and debugging process and reduces the user’s cost of use.

Rich interfaces and options:

Provide a variety of fiber optic interface types and transmission distance options to meet the needs of different users.
