TSXPBY10

TSXPBY10 is a high-performance fiber optic network product.The following is a detailed introduction to the product:

1.Product Overview

TSXPBY10 adopts advanced design and manufacturing technology and can be flexibly applied to a variety of fiber optic network environments.It has a logically independent dual-bus electrical interface,which can realize the backup of the electrical interface or the access of a single device to a dual redundant bus system,providing higher reliability and stability for network communication.

2.Product Features

Dual optical port redundancy function:

TSXPBY10 adopts a dual optical port design to realize the dual-fiber ring network redundancy function.When a fiber fails somewhere,the system can rebuild the network link within 10ms to ensure the normal communication of the system and realize the self-healing protection function of signal transmission.After the network fault is eliminated,the system will automatically recover.

TSXPBY10

Proprietary ring network protocol:

This product adopts the company’s self-developed proprietary ring network protocol Ci-ring,which does not require the setting of a root node and can quickly complete the network’s ring and de-ring functions.This feature makes TSXPBY10 more adaptable and flexible in complex fiber optic network environments.

Plug and Play:

TSXPBY10 series products are plug and play,no configuration is required,which greatly simplifies the user’s installation and debugging process.This feature enables the product to be put into use faster,reducing the user’s operating costs and time costs.

Support for multiple network topologies:

This product can support point-to-point network topologies,and realize the connection of two Profibus DP bus segments through optical fiber.At the same time,it can also support the connection of multiple network segments of Profibus DP bus on the optical fiber bus of the dual optical port chain network(up to 200).

III.Performance indicators

Data electrical interface:

9-pin Sub_D jack connector,the pin definition complies with the Profibus DP protocol specification.

Support Profibus DP bus standard.

Communication rate:

Up to 12MBit/s,the specific rate can be set by automatic identification or DIP switch.

Signal delay:

Electrical port signal delay≤11Bit;optical port signal delay≤1.6us/node.

Lightning protection and overcurrent protection:

It has 4000V lightning protection,1.5A overcurrent protection and 600W surge protection.

TSXPBY10

Fiber wavelength and transmission distance:

Multimode fiber wavelength can be 850nm and 1310nm;single-mode fiber wavelength can be 1310nm and 1550nm.

In terms of transmission distance,multimode fiber can reach 2Km,and single-mode fiber can reach 20Km(longer distance is optional).

Fiber interface type:

Optional SC,FC,ST and other interface types,standard SC optical interface.

IV.Application field

TSXPBY10 is widely used in industrial automation,communication,data center and other fields due to its high performance and flexible application characteristics.It can meet the needs of various complex fiber optic network environments and provide users with stable and reliable network communication solutions.
