TRICONEX AI3351

TRICONEX AI3351 is an analog input module.Here is a detailed introduction about it:

1.Product Overview

TRICONEX AI3351 module is an I/O board produced by TRICONEX(now part of Invensys Group)for analog input functions in industrial automation systems.It is designed for receiving and processing analog signals from sensors or measuring devices,and has the characteristics of high precision,high resolution and flexible configuration.

TRICONEX AI3351

2.Technical Features

Analog Input Channel:

AI3351 module usually has multiple analog input channels,each channel has an independent input port,which can be connected to different types of sensors or measuring devices.

The input signal range is wide,including analog signals such as voltage,current,temperature,etc.

High Precision and High Resolution:

The module provides high-precision and high-resolution analog signal acquisition and measurement capabilities,and can detect subtle signal changes.

The accuracy can reach±0.01%at 1000~20000Hz,±0.1%at 100~999Hz,and±1.0%at 20~99Hz.

Flexible configuration:

The AI3351 module has flexible configuration options,and users can adjust parameters such as sampling rate,filter settings,and input range according to specific application requirements.

Data communication:

The module can communicate data with the main controller or other devices of the TRICONEX system,and send the collected analog signals to other devices for processing and analysis through the digital communication interface.

Reliability and safety:

The AI3351 module has high reliability and safety and can operate stably in harsh industrial environments.

It has protection measures to prevent electromagnetic interference,overvoltage and other problems,and has fault detection and alarm functions.

Input characteristics:

The input timely correction rate is usually 50ms(typical value).

The input impedance(load)is usually greater than 8KΩ,and is typically 20KΩ.

The input common state range is-100V to+100V(peak-to-peak).

The input normal state range is 1.5V to 500V(peak-to-peak).

The input over-limit protection is±150VDC(continuous).

TRICONEX AI3351

3.Application fields

TRICONEX AI3351 module is widely used in the following fields:

Industrial automation:used to receive and process analog signals from various sensors and measuring devices to achieve precise control of the production process.

Process control:used to monitor and control various process parameters in the chemical,petroleum,pharmaceutical and other industries.

Environmental monitoring:collect environmental parameters such as atmosphere and water quality for environmental assessment and monitoring.

Energy management:monitor the energy consumption and performance of energy equipment,optimize energy utilization and reduce energy costs.

4.Product specifications(partial)

Brand:TRICONEX

Type:analog input module

Number of input signals:8(non-shared)

Input frequency range:20Hz to 20000Hz(it is also possible to work below 20Hz or above 20000Hz,but the accuracy and input sensitivity may vary)

Color:lavender(pulse input module)

Support system:DCS(distributed control system)

Weight:0.5(unit is not clear,it may be kilograms or pounds,etc.)
