TRICON 3009

TRICON 3009 is a highly fault-tolerant programmable and process control technology product manufactured by Triconex.Its detailed features are as follows:

1.Basic information

Manufacturer:Triconex

Product number:3009

Product type:Enhanced main processor(UMP)module

2.Core features

Triple module redundant structure(TMR):

TRICON 3009 has three identical sub-circuits,each of which performs an independent degree of control,thus providing a high degree of fault tolerance.

Adaptability to harsh industrial environments:

The product can endure harsh industrial environments and ensure stable operation under complex conditions.

TRICON 3009

Field installation and repair:

TRICON 3009 supports field installation,and can be installed and repaired on-site online without interfering with field wiring at the module level,which improves the convenience of maintenance.

I/O module support:

Supports up to 118 I/O modules(analog and digital)and optional communication modules,providing rich input and output options.

Communication Capability:

The communication module can connect to Modbus master and slave devices,or to Foxboro and Honeywell distributed control systems(DCS),as well as external hosts in TCP/IP networks.

At the same time,it also supports other Tricons in peer-to-peer networks,realizing flexible network communication.

Remote I/O module support:

Remote I/O modules up to 12 kilometers away from the mainframe can be supported,expanding the coverage of the system.

Programming software:

The control program is developed and debugged using Windows NT system-based programming software,which improves the convenience and flexibility of programming.

Intelligent functions:

Intelligent functions in input and output modules can reduce the workload of the main processor and improve the overall performance of the system.

Hardware and output modules:

Each I/O module has three microprocessors,and the output module microprocessor provides information for voting on output data.

The validity of the output state is checked through the feedback loop voltage at the output end,and field line problems can be diagnosed.

Online diagnosis and repair:

Provide comprehensive online diagnostic and repair capabilities,so that routine maintenance can be performed without interrupting the control process when the Tricon is started and running.

Hot standby support:

Provides”hot standby”support for I/O modules,which can be used in certain emergency situations where services cannot be provided in time,enhancing the reliability and availability of the system.

TRICON 3009

3.Typical applications

Emergency Safety Shutdown(ESD):

Provides continuous protection for safety-critical devices in refineries,petrochemical/chemical plants and industrial processes.

Boiler control:

Integrates protection of boilers from abnormal conditions,safety interlocks for startup and shutdown,and flame safety applications.

Turbine control:

Controls and protects gas turbines or steam turbines with high integrity and safety.

Offshore platforms:

Provides continuous availability and reliability for offshore platforms.

Fire and gas protection:

Directly connects to analog fire and gas detectors without trip amplifiers.

Replace traditional fire and gas panels with a single integrated system,saving space while maintaining a high level of safety and availability.
