TEKTRONIX 5A22N

EKTRONIX 5A22N Product Details
Product Overview
Tektronix 5A22N is a high-performance differential amplifier module designed for Tektronix 5100 series oscilloscopes. It has the characteristics of high sensitivity, high common mode rejection ratio, variable DC offset, etc., and is widely used in electronic measurement, scientific research and other fields.
Main Functions
High-gain differential amplification: can amplify weak differential signals while suppressing common mode noise.
Variable DC offset: can DC offset the input signal for easy measurement.
High frequency response: has a wide bandwidth and can measure high frequency signals.
Low noise: low noise level to ensure the accuracy of measurement results.
Product Features
High sensitivity: can measure weak signals.
High common mode rejection ratio: can effectively suppress common mode noise.
DC coupling: can measure DC signals.
Modular design: easy to install and replace.
Technical parameters (typical values)
Bandwidth: DC ~ 1MHz
Gain: 10uV/div ~ 5V/div
Input impedance: 1MΩ
Common mode rejection ratio: > 10000:1
Noise: < 20uV
Application scenarios
Electronic circuit testing: used to measure differential signals in circuits.
Sensor signal measurement: used to measure weak signals output by sensors.
Noise analysis: used to analyze noise in circuits.
