SCHROFF 140CPU65160

SCHROFF 140CPU65160 may refer to the 140CPU65160 central processing unit manufactured by Schneider Electric,which is part of the Quantum PLC(Programmable Logic Controller)series or the Quantum Automation Platform,also known as the Unity processor.The following is a detailed introduction to the processor:

1.Basic features

Model:140CPU65160

Product type:Quantum PLC series central processing unit/Unity processor

Processing power:It has powerful processing power and can handle large-scale control tasks.

Clock pulse frequency:266 MHz

II.Connection and communication

USB port:1

Distributed AS interface:2

Remote interface:4

Local Ethernet TCP/IP:6

Local Modbus Plus:6

Local Profibus DP:6

Modbus RS232/485:1

Other communication services:equipped with two local racks and one Ethernet router communication service

SCHROFF 140CPU65160

III.Input,output and storage

Local I/O:

Discrete I/O:1024 input channels and 1024 output channels(up to 27 slots)

Analog I/O:64 input channels and 64 output channels(up to 27 slots)

Remote I/O(RIO):

Discrete I/O:31,744 input channels and 31,744 output channels

Analog I/O:1984 input channels and 1984 output channels

Distributed I/O(DIO):

8000 discrete input channels and 8000 discrete output channels per network

500 analog input channels and 500 analog output channels per network

Program storage:Provides memory space for storing user-written control programs,which may include RAM(random access memory)and flash memory.

4,functional features

Integrated real-time clock:Supports time stamp and time-related control functions.

Fault diagnosis:Has fault diagnosis function to quickly detect and eliminate system faults.

Programmability:Users can write control logic in a specific programming language(such as IEC 61131-3 similar language)and load it into the central processor module.

Multiple application structures:Includes 1 cyclic/periodic main task,1 periodic fast task,128 I/O interrupt tasks,32 timer interrupt tasks and 4 auxiliary tasks,etc.

Local signaling:Includes a green LED light for Ethernet connection and a red LED for indicating Ethernet conflicts,which helps to quickly identify and solve network problems.

SCHROFF 140CPU65160

5.Electrical connection and compatibility

Electrical connection:includes a female connector SUB-D9 for connecting to the Modbus Plus network,an RJ45 connector for connecting to the Ethernet network,and an RJ45 connector specially designed for connecting to the Modbus bus.

Compatibility:supports multiple communication protocols and network connections,such as Ethernet TCP/IP,Modbus Plus,Profibus DP,etc.,and can communicate with other PLC modules,external devices and upper-level monitoring systems.
