SCHNEIDER BMXDDI1602

SCHNEIDER BMXDDI1602

Manufacturer: Schneider Electric
Product Type: Digital Input Module
Model Number: BMXDDI1602
Number of Inputs: 16
Input Voltage: 24V DC
Input Type: Sink/Source
Operating Temperature: -25°C to +70°C
Dimensions: 70 x 100 x 71 mm
Weight: 0.2 kg

The Schneider BMXDDI1602 is a digital input module designed for use with Modicon M340 programmable logic controllers (PLCs). It has 16 discrete inputs that can be used to monitor the status of various devices or sensors in an industrial automation system. The module is compact and easy to install, with a removable terminal block for simplified wiring. It is also designed to operate reliably in harsh industrial environments, with a wide operating temperature range and resistance to electrical noise and vibration.

KOLLMORGEN SEIDEL CF-SS-RHA-1HE-0​3 NSPP CFSSRHA1HE03

KOLLMORGEN SEIDEL SERVO MOTOR

FANUC AC SPINDLE SERVO UNIT A06B-6059-H215#​H517

Fanuc AC Spindle Drive A06B-6059-H226#​H607 A06B6059H226

FANUC A06B-6059-H206 USPP A06B6059H206

FANUC Spindle unit A06B-6059-H215 with 90 day warranty

Fanuc A06B-6059-H206

FANUC A06B-6059-H003 NSFP A06B6059H003

Parameters:

• Input voltage range: 18-30V DC
• Input current: 5 mA
• Input impedance: 3.9 kOhm
• Input response time: 1 ms
• Isolation voltage: 500V AC between input and internal logic
• Surge withstand: 1 kV (IEC 61000-4-5)
• Operating shock resistance: 15 g (11 ms)
• Operating vibration resistance: 5 g (10-500 Hz)
• Maximum power consumption: 3.6 W
• Backplane current consumption: 150 mA at 5V DC
