SCHNEIDER AS-B809-016

SCHNEIDER AS-B809-016

The Schneider AS-B809-016 is a digital input/output module designed for use with Modicon Quantum programmable logic controllers (PLCs). It provides 16 digital inputs and 16 digital outputs, with a voltage range of 24V DC.

The module has a maximum input current of 8 mA and a maximum output current of 0.5 A per channel. It also features LED indicators for each input and output channel, allowing for easy monitoring and troubleshooting.

The AS-B809-016 module is hot-swappable, meaning it can be replaced or added to a running system without the need for shutdown or interruption. It also has a compact design, allowing for easy installation in tight spaces.

Overall, the Schneider AS-B809-016 is a reliable and versatile digital I/O module that can be used in a variety of industrial automation applications.

FANUC A20B-1000-0560/​11F SERVO ANALOG BOARD

TEDEA HUNTLEIGH MODEL 9010 DAMPED LOAD CELL NIB

INGERSOLL RAND 93969939 DC MOTOR SYSTEM

PULSAFEEDER BOILER PROBE 16-972-13 16-972-14 NEW

NEW EMERSON TP-30H X1 POWER TRANSMISSION PART TP30HX1

TOTAL CONTROL QPK2D100S2P QUICKPANEL JR.SER.A

ZAYTRAN INC.GPLN-40 GRIPPER GPLN40 NEW

NIB IKO NAS 5020 UUNR BEARING NAS5020UUNR

The module has 16 inputs that can be configured as either sinking or sourcing inputs, depending on the requirements of the application. It supports a wide range of input voltages, from 5VDC to 24VDC, and has a maximum input frequency of 10 kHz.

The AS-B809-016 module is designed for easy installation and maintenance. It features a removable terminal block for easy wiring and a status LED for each input channel to indicate the status of the input signal.

Some of the key features and parameters of the Schneider AS-B809-016 module include:

• 16 digital inputs
• Sinking or sourcing input configuration
• Input voltage range: 5VDC to 24VDC
• Maximum input frequency: 10 kHz
• Removable terminal block for easy wiring
• Status LED for each input channel
• Designed for use with Modicon Quantum PLCs.
