SCHNEIDER 140NOE77111

SCHNEIDER 140NOE77111

The Schneider 140NOE77111 is an Ethernet communication module designed for use with Modicon Quantum programmable logic controllers (PLCs). It provides a high-speed Ethernet connection for remote I/O and peer-to-peer communication between PLCs.

Product Information:

• Manufacturer: Schneider Electric
• Product Type: Ethernet Communication Module
• Model Number: 140NOE77111
• Series: Modicon Quantum
• Communication Protocol: Ethernet/IP, Modbus TCP/IP
• Communication Ports: 1 RJ45 Ethernet port
• Power Supply: 5 VDC
• Operating Temperature: 0°C to 60°C
• Dimensions: 1.57 x 3.54 x 5.12 inches
• Weight: 0.33 lbs

The Schneider 140NOE77111 is an Ethernet communication module designed for use with Modicon Quantum programmable logic controllers (PLCs). It provides a high-speed Ethernet interface for communication with other devices on the network, including other PLCs, HMIs, and SCADA systems. The module supports a variety of communication protocols, including Modbus TCP/IP, EtherNet/IP, and Profinet IO. It also features a built-in web server for remote configuration and monitoring. The 140NOE77111 is designed for use in industrial environments and is built to withstand harsh conditions, including extreme temperatures, humidity, and vibration.

KLA-Tencor 2365 VA Shutter Driver D880C working

KLA-Tencor AIT2 Power Assembly LPM 390500

KLA-Tencor Tropel Lens Assy.0099750-000 untested

KLA-Tencor AIT 2 UI Splitter Board 547247 AA working

KLA-Tencor 2365-UI Marathon G580 1/3HP Motor Fan

KLA-Tencor KLA 2365-UI Marathon G580 1/3HP Motor Fan

KLA-Tencor 2365-UI Axis PCB Assy 3900047-D Working

Parameters:

• Maximum Number of Connections: 128
• Maximum Number of I/O Scanning: 256
• Maximum Number of TCP/IP Connections: 16
• Maximum Number of UDP Connections: 16
• Maximum Number of Modbus TCP/IP Connections: 16
• Maximum Number of Ethernet/IP Connections: 16
• Maximum Number of Peer-to-Peer Connections: 16
• Maximum Data Size per Connection: 8192 bytes
• Maximum Number of I/O Data: 2048 bytes
• Maximum Number of I/O Words: 1024 words
• Maximum Number of I/O Registers: 512 registers
• Maximum Number of I/O Bits: 8192 bits
