SCHNEIDER 140NOE77111

SCHNEIDER 140NOE77111

Product Information:

• Brand: Schneider Electric
• Model: 140NOE77111
• Series: Modicon Quantum
• Communication Protocol: Ethernet
• Communication Rate: 10/100 Mbps
• Number of Ports: 1
• Operating Temperature: 0 to 60°C
• Storage Temperature: -40 to 85°C
• Dimensions: 119 x 30 x 126 mm
• Weight: 0.2 kg

The Schneider 140NOE77111 is an Ethernet communication module designed for use with Schneider Electric’s Quantum programmable logic controllers (PLCs). It provides a high-speed Ethernet connection for remote I/O and Modbus TCP/IP communication between the PLC and other devices on the network. The module has a compact design and supports up to 8 connections with a maximum data transfer rate of 100 Mbps. It also features a web server for remote configuration and monitoring, as well as diagnostic LEDs for easy troubleshooting.

GE AKR-10D-75 3200 A Amp Air Breaker MVT Plus Trip 635V

GE AKR-7D-100 4000 A Amp Breaker RMS-9 MVT Trip 635 V

GE 3200A Air Circuit Breaker CAT#AKR-10D-75 M/O D/O

GE AKR-7D-75 3200 A Amp Breaker RMS-9 MVT Trip LS 635 V

GE AKR-7D-100 4000 A Amp Low Voltage Air Breaker 635 V

GE AKR-10D-100 4000 A Amp Low Voltage Air Breaker 635V

GE 1600A Air Circuit Breaker CAT#AKR-10D-50H M/O D/O

GE AKR-9D-100 4000 A Amp Low Voltage Air Breaker 635 V

Parameters:

• Input Voltage: 24 VDC
• Power Consumption: 4 W
• Network Topology: Daisy Chain, Star, or Ring
• Maximum Number of Nodes: 64
• Maximum Distance between Nodes: 100 m
• Supported Protocols: Modbus TCP/IP, EtherNet/IP, Profinet IO, and Modbus TCP/IP Scanner
• Memory: 2 MB Flash, 16 MB RAM
• LED Indicators: Power, Network, and Module Status
• Certifications: CE, UL, CSA, and C-Tick
