SCHNEIDER 140CPS21400

SCHNEIDER 140CPS21400

• Manufacturer: Schneider Electric
• Product Type: Power Supply Module
• Model Number: 140CPS21400
• Series: Quantum
• Input Voltage: 85-264VAC
• Output Voltage: 5.1VDC
• Output Current: 40A
• Mounting Type: DIN Rail
• Dimensions: 4.13 x 5.12 x 10.24 inches
• Weight: 2.2 pounds

The Schneider 140CPS21400 is a power supply module from the Quantum series of programmable logic controllers (PLCs) manufactured by Schneider Electric. It is designed to provide a reliable and stable power source for the Quantum PLC system, ensuring uninterrupted operation and protection against power surges and other electrical disturbances. The module has a power rating of 24V DC and a maximum output current of 14A, making it suitable for a wide range of industrial applications. It features a compact and modular design, allowing for easy installation and maintenance, and is compatible with various communication protocols, including Modbus, Ethernet, and Profibus.

MODICON 110-CPU-311-00 NSFP 110CPU31100

Gould Modicon AEG Circuit Board AS-516P-007 _ AS516P007

MODICON MM-PM10-300C USPP MMPM10300C

MODICON 140-ATI-030-00 NSFP 140ATI03000

MODICON 140-CPS-224-00 NSPP 140CPS22400

MODICON AS-B838-032 NSPP ASB838032

MODICON AM-C924-000 USPP AMC924000

MODICON AS-212P-010 USPP AS212P010

MODICON AS-212P-110 USPP AS212P110

Parameters:

• Input Voltage Range: 85-264VAC
• Input Frequency Range: 47-63Hz
• Output Voltage Range: 4.75-5.25VDC
• Output Current Range: 0-40A
• Efficiency: 93%
• Operating Temperature Range: -25°C to +70°C
• Storage Temperature Range: -40°C to +85°C
• Humidity: 5-95% non-condensing
• Overvoltage Protection: Yes
• Overcurrent Protection: Yes
• Short Circuit Protection: Yes
• MTBF: 500,000 hours
