SCHNEIDER 140CPS11420

SCHNEIDER 140CPS11420 is a power module produced by Schneider Electric,belonging to the Modicon Quantum series.The following is a detailed introduction to the product:

1.Basic features

Main use:Provide power support for controllers and other devices in industrial automation systems.

Power supply type:Provide DC or AC power to meet the needs of different types of equipment.

Output voltage:The output to the bus is 5.1 volts DC.

Input voltage range:

Accepts 115 volts or 230 volts AC as input.

Specific ranges include 115V(93-132V)AC 47-63Hz,or 230V(170-276V)AC.

Input current:

The input current is 1300mA on 115V.

The input current is 750mA on 230V.

Inrush current:At 230V input,the inrush current is 19A.

Rated power:130VA.

SCHNEIDER 140CPS11420

2.Technical Specifications

Terminals of the terminal block:

Terminals 1 and 2 have a rated voltage of 220 volts AC.

Terminals 1 and 2 also have normally closed relay contacts of 6 amps/30 volts DC,5A.

Input frequency:can be between 47-63 Hz.

Voltage total harmonic distortion:less than 10%of the fundamental RMS value.

Protection function:has internal output overvoltage protection and output overload protection.

Electromagnetic compatibility:

Good resistance to electromagnetic interference.

Can withstand 10V/m electromagnetic field interference in the frequency range of 80-2000MHz,in accordance with IEC 801-3 standard.

The electromagnetic interference generated by itself is low and will not have adverse effects on surrounding electronic equipment.

SCHNEIDER 140CPS11420

3.Application environment and status indication

Working environment temperature:0-60°C.

Storage environment temperature:-40-85°C.

Relative humidity:95%without condensation.

Working altitude:≤5000m.

Status indication:Equipped with 1 green LED indicator to display the power status.When the power supply is working properly,the green light is on.
