The PILZ PSSSBDI808 is a safety-related digital input module. It is used in safety-critical applications to detect machine states or events and send signals to a safety control system.

Some key features and parameters of the PSSSBDI808 module include:

• Inputs: The module has 8 digital input channels.
• Safety Integrity Level (SIL): SIL 3 according to IEC 61508.
• Input voltage: It can operate with a wide range of input voltages, typically between 24VDC and 110VDC.
• Input type: The module supports both PNP and NPN sensor types.
• Diagnostic functions: The module provides built-in diagnostic functions for continuous monitoring of inputs, including short-circuit and wire-break detection.
• Safety communication: It uses a safe communication protocol to transmit safety-related signals to the central safety control system.
• Redundancy: The module supports redundant wiring for enhanced safety and availability.
• Configuration: It can be configured using the PILZ PSS programming software or other compatible software tools.

ASEA BROWN BOVERI ACS201-2P7-3-00​-10 USPP ACS2012P73001

ASEA BROWN BOVERI DSFS-11 USPP DSFS11

ASEA BROWN BOVERI DSFS-14 USPP DSFS14

ASEA BROWN BOVERI YT212001-AB USPP YT212001AB

ASEA BROWN BOVERI S3NQ150TWAS8 NSFP S3NQ150TWAS8

ASEA BROWN BOVERI 468T2675 NSFP 468T2675

ASEA BROWN BOVERI 468T3575 NSFP 468T3575

The PSSSBDI808 module is part of the PSS 4000 automation system, a scalable and modular safety solution. It offers 8 safe digital inputs and 8 safe digital outputs, allowing it to handle safety signals from various devices and provide safe control outputs to actuate safety devices.

Key features of the PILZ PSSSBDI808 include:

1. Safety functions: The module is capable of handling various safety functions such as emergency stop, two-hand control, light curtains, and safety gates.
2. Diagnostic capabilities: The module provides comprehensive diagnostics to detect faults and failures in the safety system, ensuring high levels of safety and reliability.
3. Communication: It supports various communication interfaces such as Ethernet/IP and Modbus TCP/IP, allowing it to seamlessly integrate into existing automation networks.
4. Programming flexibility: The safety PLC module can be programmed using the intuitive PSS WIN-PRO programming software. It offers a wide range of programming options, including graphical function block programming and textual programming languages such as PASIL language.
5. Expansion options: The PSSSBDI808 module can be easily expanded by adding additional I/O modules or safety controllers from the PILZ PSS range, making it suitable for applications of different sizes and complexities.

Overall, the PILZ PSSSBDI808 is a versatile safety PLC module that offers robust safety features, flexible programming options, and seamless integration capabilities. It is suitable for a wide range of applications, providing reliable and efficient safety control in automation systems.
