The MVI69-MCM is a PROSOFT communication module that allows users to connect Rockwell Automation’s ControlLogix platform with Modbus TCP/IP devices. Here are some key product information and parameters:

• Compatibility: The MVI69-MCM is designed to be used with ControlLogix controllers from Rockwell Automation. It supports Modbus TCP/IP communication protocol.
• Communication Interface: The module provides an Ethernet interface for communication with Modbus TCP/IP devices. It supports up to 12 TCP/IP client connections and 128 total connections.
• Data Transfer: The MVI69-MCM allows bi-directional data transfer between the ControlLogix processor and Modbus TCP/IP devices. It supports both read and write operations.
• Data Types: The module supports a wide range of data types, including integer, floating-point, double-precision, boolean, and more. It also supports string and bit operations.
• Modbus Function Codes: The MVI69-MCM supports Modbus function codes 1, 2, 3, 4, 5, 6, 15, and 16, allowing users to read and write coils, discrete inputs, holding registers, and input registers.
• Diagnostics: The module provides various diagnostic features, such as real-time status and error reporting, as well as configuration and diagnostic messaging. It also supports diagnostic alarms that can be monitored by the ControlLogix processor.
• Configuration: The MVI69-MCM module is configured using the Rockwell Automation RSLogix 5000 programming software. Users can set up the module’s IP address, Modbus device addressing, and other parameters through the software.
• Redundancy: The MVI69-MCM module supports redundant communication with primary and secondary Ethernet networks, ensuring high availability and reliability.
• Power Supply: The module requires a 5V DC power supply, which can be obtained from the ControlLogix backplane.
• Documentation: PROSOFT provides user manuals, configuration guides, and other documentation for the MVI69-MCM module, helping users with installation, configuration, and troubleshooting.
