MS-NAE5510-2

MS-NAE5510-2 is a powerful network control engine.Here is a detailed introduction to it:

1.Product Overview

The MS-NAE5510-2 is produced by Johnson Controls and is a network controller of the Metasys MS series.It has powerful integration capabilities,efficient and reliable processors,and a user-friendly interface.It is designed to integrate with various building systems,including but not limited to HVAC,lighting,access control and security systems,allowing building managers to monitor and control various systems throughout the building through a single platform.

MS-NAE5510-2

2.Main Features

Powerful integration capabilities:

The MS-NAE5510-2 can be easily integrated into various building systems for comprehensive monitoring and control.

Efficient and reliable processor:

Equipped with a powerful processor,it ensures fast and efficient control of building systems,optimizes energy use,reduces operating costs,and improves building operation efficiency.

User-friendly interface:

Built-in network server provides a user-friendly interface,allowing building managers to easily manage and maintain building systems.

Multiple communication protocol support:

Supports multiple communication protocols such as BACnet,Modbus and LonWorks,and can be seamlessly integrated with various devices and systems.

Rich ports and interfaces:

Provide a variety of ports and interfaces such as Ethernet,RS-485,RS-232 and USB,allowing connection and communication with other systems.

Large-capacity storage:

With 4GB of flash memory and 1GB of SDRAM,it supports efficient operation and data processing.

Electrical backup and real-time timing:

The real-time timing device with backup battery ensures that data is protected from loss in the event of power failure.

Power supply and installation:

Equipped with LED for power reminder,easy to replace after a problem occurs.Removable screw-fixed terminal 24VAC power supply,supports screw installation or placement on DIN rail.

MS-NAE5510-2

III.Technical specifications

Power supply voltage:generally 24VAC,can work in the voltage range of 20~30VAC.

Power supply frequency:standard 50/60Hz.

Power consumption:50VA.

Weight:6.4 pounds(2.9 kg).

Port configuration:

Ethernet port:supports 10Mbps,100Mbps and even 1000Mbps baud rates,using RJ-45 eight-pin connector.

RS-485 ports:two,with four different baud rates ranging from 9.6k to 76.8k.

RS-232-C ports:two,requiring a suitable cable and a connector with nine pins.

USB ports:two,must use a connector suitable for USB.

IV.Application areas

The MS-NAE5510-2 network control engine is suitable for various large commercial buildings,such as office buildings,shopping malls,hospitals,etc.,for realizing intelligent management and control of building systems.
