Moog M128-010 and M128-010-A001B Servo Valve Description, Product Parameters, and Product Specification
Description:
The Moog M128-010 and M128-010-A001B are high-performance servo valves designed for precise control of fluid flows in industrial and aerospace applications. These servo valves are typically used in closed-loop control systems to regulate the position, velocity, or force of actuators.
The M128-010 series servo valves offer fast response times, high repeatability, and excellent control accuracy. They are suitable for use with a wide range of fluids, including hydraulic and pneumatic media.
The M128-010-A001B variant may refer to a specific configuration or modification of the basic M128-010 design, tailored to meet specific application requirements.
Product Parameters:
Flow Rate: The maximum flow rate through the servo valve, measured in liters per minute (LPM) or cubic feet per minute (CFM).
Control Signal: The type and range of control signal accepted by the servo valve, such as analog voltage or current.
Response Time: The time taken by the servo valve to reach a steady-state condition in response to a change in the control signal.
Control Accuracy: The precision with which the servo valve can control the fluid flow.
Operating Pressure: The range of pressures at which the servo valve can operate safely.
Operating Temperature: The range of temperatures within which the servo valve can operate without damage.
Valve Configuration: The number and type of ports, as well as the arrangement of the spool or poppet within the valve body.
Product Specification:
The Moog M128-010 and M128-010-A001B servo valve specifications provide detailed technical information about the product’s capabilities and performance characteristics. The specification may include:
Dimensional Drawings: Detailed drawings showing the dimensions and connections of the servo valve.
Flow Curves: Plots showing the relationship between flow rate and control signal.
Response Time Charts: Graphs depicting the response time of the servo valve under different conditions.
Material Specification: Details of the materials used in the construction of the servo valve, including the spool, body, and seals.
Certifications and Compliance: Information on any certifications or compliance marks held by the servo valve, such as ISO or CE certification.
Please note that the actual parameters and specifications of the Moog M128-010 and M128-010-A001B servo valves may vary depending on the specific configuration and application. It is recommended to refer to the official documentation or contact Moog for detailed and accurate information.
M128-010 M128-010-A001B moog
M128-010 M128-010-A001B moog
M128-010 M128-010-A001B moog
