IS220PSCAH1A GE I/O module

Product Description

IS220PSCAH1A is a serial Modbus communication I/O module manufactured by General Electric and is part of the Mark VIe series used in gas turbine control systems.

feature

Has multiple analog input channels and/or analog output channels 4.

Has the ability to perform self diagnostic tests and can monitor analog inputs,positions,and pressures.

IS220PSCAH1A is a serial Modbus communication I/O module manufactured by GE,specifically designed for General Electric’s Mark VIeS control system.

The IS220PSCAH1A GE I/O module provides an interface between up to two input/output Ethernet networks and one serial communication board,with six individually configurable serial transceiver channels that can be used for RS485 half duplex,RS232,and RS422 standard 2

The IS220PSCAH1A I/O module is used for serial Modbus communication.This package is designed for General Electric’s Mark VIeS control system.When using this package,it can provide interfaces between up to two input/output Ethernet and serial communication boards.This board has 6 individually configurable serial transceiver channels and can be used in conjunction with RS485 half duplex,RS232,and RS422 standards.The input required to power the PSCA group is sent through a three pin power input and dual RJ45 Ethernet connectors.

There is a serial Modbus main service on the IS220PSCAH1A I/O module,which has many different functions,some of which are as follows:

Remote terminal equipment

Data bits:seven,eight

32-bit data word order

Parity check:even,none,odd

Station address

These features are used for the six configurable ports on the PSCA package.Configuration can be completed at the port level.With the help of PSCA,the two Ethernet ports on the packaging can be used to help support the Ethernet Modbus main protocol;Please note that this configuration can only occur when used on a simplex network.

The IS220PSCAH1A I/O module is capable of performing self diagnostic tests,one of which is to monitor analog inputs,position and pressure to check configurable high and low levels.These restrictions are used to enable and disable features,lock/unlock,and generate alerts.Some possible alarms include 32-67,114-119,108-113,and 72-107.All these alarms indicate different errors.

application area

The IS220PSCAH1A GE I/O module is widely used in industrial automation systems,including manufacturing,chemical,power,oil and gas,water treatment,and other fields.
