Product Overview:

GPIB-140A is an advanced interface card that adopts the GPIB (General Purpose Interface Bus) standard, also known as IEEE 488 interface. This interface standard is widely used in measurement and automation fields to connect instruments, devices, and computers for data communication and control functions.

Specifications & Parameters:

Interface Standard: Implements the GPIB (IEEE 488) standard for seamless connectivity and communication with various test and measurement devices.
Pulse Control: Designed for pulse control applications, capable of generating and controlling pulse signals with adjustable parameters such as frequency, amplitude, width, and phase.
Control & Communication: Supports up to 8 parallel devices for control and communication, with a maximum transmission rate of 1.5 MB/s.
Compatibility: Compatible with IEEE 488.1 and IEEE 488.2 standards, suitable for use with Windows, Linux, and Mac OS operating systems.
Dimensions & Weight: Measures approximately 14 cm x 10 cm x 2 cm and weighs 100 grams.
Operating Conditions: Operates within a temperature range of 0°C to 55°C and storage temperature of -40°C to 70°C.
Power Consumption: Supports a voltage of 5 V and has a maximum power consumption of 2 W.

Features:

Versatility: Supports various types of GPIB devices, instruments, controllers, and analyzers, making it suitable for a wide range of testing and measurement applications.
Extensibility: Its fiber optic expansion capabilities enable the connection of test equipment over longer distances, enhancing flexibility and reach in testing and measurement systems.

Application Fields:

GPIB-140A finds extensive application in various testing and measurement fields, including automation testing, data acquisition, signal generators, and more. Its pulse control functionality and compatibility with a wide range of devices make it a valuable tool in scientific research laboratories, engineering facilities, and industrial settings.

Please note that the specifications and parameters provided may be subject to change based on manufacturer updates or product variations. It is recommended to consult the official documentation or contact the manufacturer for the most up-to-date and accurate information on GPIB-140A.
