GE-SR469-P5-HI-A20-E

GE-SR469-P5-HI-A20-E Product Details, Specifications, Parameters, and Application Fields

Product Details:

The GE-SR469-P5-HI-A20-E is a motor management relay designed by General Electric specifically for mid-voltage motors. This relay offers integrated management and protection functions, ensuring the smooth and reliable operation of motor systems.

Product Specifications:

Design and Construction: The SR469-P5-HI-A20-E features a 5-ampere phase CT secondary winding and is part of the SR 469 motor management relay series.
Control Power: It provides a wide range of control power options, including 70-265 VAC and 90-300 VDC, catering to various power requirements.
Front Panel: The relay boasts an enhanced front panel with a large 40-character LCD display, allowing users to locally view diagnostic messages such as trips or alarms.

Product Parameters:

Protection Functions: The SR469-P5-HI-A20-E offers a range of protection functions, including overload, short-circuit, and phase loss protection, ensuring the safety of motors and circuits.
Performance: This relay is designed for high sensitivity and quick response, accurately detecting and responding to the operating status of motors.
Durability: Constructed from heat-resistant and corrosion-resistant materials, it ensures a long service life and reliable performance.

Application Fields:

The GE-SR469-P5-HI-A20-E motor management relay finds extensive application in various industrial and commercial settings. Some of its key application areas include:

Automation Systems: It is often integrated into automation systems, providing precise motor control and protection for machines and equipment.
Power Generation: In power plants, the relay helps ensure the reliable and efficient operation of generators and turbines.
Transportation: It can be used in various transportation systems, such as railways and marine vessels, for motor control and safety functions.

Overall, the GE-SR469-P5-HI-A20-E motor management relay is a highly capable and versatile product, offering advanced motor control and protection features suitable for a wide range of industrial applications.
