GE SR469-P5-HI-A20-E

SR469-P5-HI-A20-E is a motor management relay from GE Multilin,part of the SR 469 motor management relay series.The following is a detailed introduction to the product:

I.Product Overview

The SR469-P5-HI-A20-E relay is designed for medium voltage motors,providing integrated management and protection functions.The unit is designed with a 5 amp phase CT secondary winding and is equipped with an enhanced front panel for user-friendly operation and monitoring.

GE SR469-P5-HI-A20-E

II.Product Features

Control Power Supply:

Provides a control power supply range of 70-265 VAC,90-300 VDC to adapt to different power supply environments.

Front Panel Design:

The front panel is well designed and easy to use.Includes an RS-232 program port interface with a 9600 baud rate and can be programmed to 19200 baud rate.

There is a sealable extraction handle on the panel to prevent unauthorized removal.

Equipped with a large 40-character LCD display,users can view diagnostic messages such as trips or alarms locally through this display.

Indicators and buttons:

The front panel also features motor and output status indicators,device indicators,numeric keypad,control and programming keys.

Includes reset,exit and menu buttons,as well as value keys that allow the user to change set values.

3.Application scenarios

SR469-P5-HI-A20-E relays are mainly used for the management and protection of medium-voltage motors,and are suitable for industrial automation occasions that require integrated management and protection functions.

GE SR469-P5-HI-A20-E

4.Technical specifications

Brand and model:GE SR469-P5-HI-A20-E

Current specifications:5 amp phase CT secondary winding

Control power supply:70-265 VAC,90-300 VDC

Communication interface:RS-232 program port interface,9600 baud rate(programmable to 19200 baud rate)

Front panel:Enhanced design,including LCD display,indicators,buttons,etc.
