GE IC698PSA100

GE IC698PSA100 is a high-performance industrial automation control module produced by GE(General Electric).The following is a detailed introduction to the module:

1.Module type and function

Type:Multi-function power supply module.

Function:This module provides+5VDC,+12VDC and-12VDC power supplies and logic level sequence signals to other modules on the backplane to ensure stable power supply for industrial automation and control systems.

GE IC698PSA100

2.Technical specifications and parameters

Power input:

AC input:85 to 264V(nominal 120/240V),47 to 63Hz.

DC input:100 to 150V(nominal 125V).

Power output:

+5VDC:output up to 20A.

+12VDC:output up to 2A(some literature mentions a nominal output of up to 2.5A at+12VDC,but the output is usually 2A).

-12VDC:Output up to 1A(some data mentions a nominal output of up to 3.5A at-12VDC,but the output is usually 1A).

Output power:At an ambient temperature of 0°C to 60°C,the total output power allowed is 100 watts(some data mentions a nominal output power of 125 watts,but the output power is usually 100 watts).

Other parameters:

Pass-through and hold time:The minimum pass-through time is 15 milliseconds and the minimum hold time is 5 milliseconds.

Protection function:With overcurrent,overheating and overvoltage protection.

Isolation voltage:The isolation voltage in the module is 1500VDC.

III.Structure and installation

Structure:A simple slide-in rack mounting structure is adopted for easy installation and maintenance.

Installation position:Directly inserted into the leftmost slot of the standard RX7i series rack,that is,slot 0.

IV.Indicator and switch

Indicator:The LED indicator is used to display the field and output status.The LED indicator will light up when the power supply is within the acceptable range and the DC output channel is working normally.

Switch:There is a two-position on/off switch on the front panel to enable or disable the output channel without interrupting the AC line input.

5.Application Fields

GE IC698PSA100

The IC698PSA100 multi-function power supply module is widely used in various industrial automation and control systems,including but not limited to the following fields:

Manufacturing:Provide stable power for production lines,machines and automation equipment.

Process control:Provide power for control systems,sensors and actuators in chemical,petroleum,food processing and other fields.

Power industry:Power distribution,power generation and substation equipment.

Building automation:In building management systems,power lighting,HVAC,security systems and other equipment.

Water treatment:Power treatment equipment and monitoring systems in water treatment plants and sewage treatment plants.

Traffic control:Power traffic lights,railway signals and tunnel safety equipment.
