GE IC698PSA100

Status: In Stock

Output voltage:Provides three output voltages:+5VDC,+12VDC and-12VDC.

+5VDC:Output up to 20A.

+12VDC:Output is typically 2A(some literature mentions nominal outputs as high as 2.5A).

-12VDC:Output is typically 1A(some sources mention nominal outputs as high as 3.5A).

Output power:The total output power allowed is 100 watts at an ambient temperature of 0°C to 60°C(some sources mention a nominal output power of 125 watts,but the usual output power is 100 watts).

IC698PSA100 is a multi-functional power module produced by GE Fanuc for the RX7i series.The following is a detailed introduction to the power module:

1.Basic characteristics

Versatility:The module is versatile and capable of providing stable power and logic level sequencing signals to modules on the backplane.

Stability and reliability:It plays an important role in industrial automation and control systems and is known for its stability and reliability.

2.Power output

Output voltage:Provides three output voltages:+5VDC,+12VDC and-12VDC.

+5VDC:Output up to 20A.

+12VDC:Output is typically 2A(some literature mentions nominal outputs as high as 2.5A).

-12VDC:Output is typically 1A(some sources mention nominal outputs as high as 3.5A).

Output power:The total output power allowed is 100 watts at an ambient temperature of 0°C to 60°C(some sources mention a nominal output power of 125 watts,but the usual output power is 100 watts).

3.Electrical specifications

AC input:85 to 264V(120/240V nominal),47 to 63Hz.

DC input:100 to 150V(125V nominal).

Isolation voltage:The isolation voltage in the module is 1500VDC.

GE IC698PSA100插图

GE IC698PSA100

4.Installation and connection

Installation location:Directly inserted into the leftmost slot of the standard RX7i series rack,that is,slot 0.

Connection method:

Connections must be made using AWG#16(1.3mm²)solid or stranded copper wire with an insulation rating of 75°C(167°F).

Use AWG#12(3.3mm²)copper wire with an insulation rating of 75°C(167°F)for the ground connection.

5.Protection function

This module has overcurrent,overheating and overvoltage protection functions to ensure the protection of the power module and the entire system when an abnormality occurs in the system.

6.Indicator lights and switches

Indicator light:LED indicator light is used to display site and output status.When the power supply is within the acceptable range and the DC output channel is working normally,the LED indicator will light up.

Switch:A two-position on/off switch on the front panel enables or disables the output channels without interrupting the AC line input.

7.Application fields

GE IC698PSA100插图1

GE IC698PSA100

IC698PSA100 multi-function power module is widely used in various industrial automation and control systems,including but not limited to the following fields:

Manufacturing:Provide stable power supply for production lines,machines and automation equipment.

Process control:Provide power for control systems,sensors and actuators in chemical,petroleum,food processing and other fields.

Electric power industry:Supplies power distribution,generation and substation equipment.

Building Automation:In building management systems,power is provided for lighting,HVAC,security systems and other equipment.

Water treatment:Powering treatment equipment and monitoring systems in water treatment plants and wastewater treatment plants.

Traffic Control:Powers traffic lights,railway signals and tunnel safety equipment.
