GE IC697MDL750

GE IC697MDL750

The GE IC697MDL750 is a 32-point discrete output module that is part of the GE Fanuc Series 90-70 PLC system. It provides 32 output points in four isolated groups of eight points each. Each output point is capable of sinking up to 1.0A of current at 24VDC. The module is designed to operate in a temperature range of 0 to 60 degrees Celsius and can be mounted on a DIN rail or in a rack. It is compatible with a variety of programming languages, including ladder logic, function block diagram, and structured text. The module is commonly used in industrial automation applications to control the operation of motors, valves, and other devices.

HP 8568A SPECTRUM ANALYZER W/85662A DISPLAY

Fluke 96B SCOPEMETER Series II 60 MHz

Adept SCSI VME SIO 30330-12350/103​30-12350 MODULE ROBOT

SIEMENS SIMATIC 6ES5 304-3UB11 S5 INTERFACE MODULE(NEW)

NSK LH25 Z Actuator Qty4 Linear Motion Guide Rail Qty2

NOVELLUS 02-8105157-00 ASSY,SYS.CONT,P​166/64,24V

NOVELLUS 02-8105005-00 MOD CNT,P166,24V,W/​8 RS232

TOHNICHI 3.6 BTG A S TORQUE GUAGE 3.6-0.05 LBF-IN

The GE IC697MDL750 is a 24VDC Positive/Negative Logic Input Module for the GE Fanuc Series 90-70 PLC system. It has 32 input points and supports both sinking and sourcing inputs.

Some of the key parameters of the IC697MDL750 module include:

• Input voltage range: 18-30VDC
• Input current: 7mA per point
• Input response time: 1ms
• Isolation voltage: 1500VDC between field and logic circuits
• Operating temperature range: 0-60°C
• Storage temperature range: -40 to 85°C
• Dimensions: 12.4 x 4.9 x 2.8 inches
• Weight: 1.5 pounds

The IC697MDL750 module is commonly used in industrial automation applications to monitor the status of sensors and switches, and to provide input signals to the PLC for processing and control.
