GE IC697MDL740

GE IC697MDL740

The GE IC697MDL740 is a high-density input module designed for the GE Series 90-70 PLC system. It provides 32 discrete input points that are compatible with a variety of sensors and devices. The module is designed to be hot-swappable, allowing for easy installation and maintenance. It supports both AC and DC input voltage ranges, and features LED indicators for each input point to provide visual status indication. The module is designed for reliable operation in industrial environments, with built-in protection against electrical noise and transient voltage spikes. It is compatible with the GE Genius I/O system, allowing for flexible and scalable system configurations.

Xycom VMEbus DIO XVME-240 P/N 70270-001

Xycom VMEbus SRM XVME-010 P/N 70010-001

XYCOM XVME-202 p/n 70202-001 SA-PAMUX

Xycom XVME-682 VMEbus CPU Module NEW!

XYCOM XVME-201 DIGITAL I/O CONTROLLER CARD PANDUIT

XYCOM AIN XVME-560 PCB VME Bus

Xycom XVME-400 Quad Serial Interface Board

Xycom Floppy Disk/Hard drive card PArt#XVM5E-95

The GE IC697MDL740 is a 12/24VDC Positive/Negative Logic Input module for the GE Fanuc Series 90-70 PLC system. It provides 32 input points in four isolated groups of eight. The module is designed to accept a wide range of input voltages, from 5VDC to 30VDC, and can be configured for either positive or negative logic.

The following are the key parameters of the IC697MDL740 module:

• Input voltage range: 5VDC to 30VDC
• Input current: 5mA per point
• Isolation: 1500VAC for 1 minute between field side and logic side
• Input response time: 5ms typical
• Input filtering: 3.2ms typical
• Input type: sinking or sourcing
• Input impedance: 3.3kΩ
• Input status indicators: LED for each input point
• Operating temperature range: 0°C to 60°C
• Storage temperature range: -40°C to 85°C
• Humidity: 5% to 95% non-condensing
• Dimensions (HxWxD): 12.4cm x 14.0cm x 3.5cm
• Weight: 0.4kg

The IC697MDL740 module is commonly used in industrial automation applications for monitoring and controlling various types of input signals, such as switches, sensors, and other digital devices. It is a reliable and cost-effective solution for expanding the input capacity of the GE Fanuc Series 90-70 PLC system.
