GE IC697MDL653

GE IC697MDL653

The GE IC697MDL653 is a 24VDC Positive/Negative Logic Input module for the GE Fanuc Series 90-70 PLC system. It provides 32 input points in four isolated groups of eight. Each group has a common power input terminal and a common return terminal. The module is designed to accept both positive and negative logic signals and has a high input impedance of 3.2 kOhms. The input voltage range is 18-30VDC and the maximum input current is 7mA per point. The module has LED indicators for each input point to indicate the status of the input signal. It also has a built-in self-test feature to ensure proper operation. The module is hot-swappable, meaning it can be replaced without shutting down the system.

Allen-Bradley Dataliner 2706-D21J8 Ser.B Rev.B WORKING

Baumuller Nurnberg DSG 71-K 1.95kW Nr.922 17337

Siemens OPM-02 6SE32900xx878BF​0 6SE3-290-0xx87-​8BF0

CONVUM F-1 CVF-1-10HS1+CVF-D1 8Y16 Vacuum Sensor NEW

JUKI New 40016466 400-16466 Rev.06 PWR PCB B Assy

PTS L320 Freq Synthesizer 10-320Mhz L320R1N1X-96/X-​108

2 x 232OPDR B&B Electronics RS-232 Optical Isolator Rep

Rohde&Schwarz SMIQ03B 300KHz 3.3GHz+NEW Calibration

Rohde&Schwarz SME 06 5KHz 6.0GHz+NEW Calibration

The GE IC697MDL653 is a 24VDC Positive/Negative Logic Input module for the GE Fanuc 90-70 Series PLC. It has 32 input points, which can be configured as either sinking or sourcing inputs. The module is designed to be used in a wide range of industrial applications, including process control, manufacturing, and automation.

Some of the key features and parameters of the GE IC697MDL653 module include:

• Input voltage range: 18-30VDC
• Input current: 7mA per point
• Input type: Positive/Negative Logic
• Input isolation: 1500VAC for 1 minute
• Input response time: 1ms
• Input filtering: 3.5ms
• LED indicators for each input point
• Hot-swappable design for easy replacement
• Operating temperature range: 0-60°C
• Storage temperature range: -40-85°C
• Dimensions: 12.2 x 4.9 x 2.8 inches
• Weight: 1.5 pounds
