## Product Details for GE IC697MDL653

The GE IC697MDL653 is a 32-point, 24 VDC discrete input module designed for use in GE Series 90-70 Programmable Logic Controllers (PLCs). It is part of GE Fanuc’s Series 90-70 I/O module family, which offers a wide range of input, output, and communication modules for expanding the capabilities of Series 90-70 PLCs. The IC697MDL653 is specifically designed for applications that require monitoring and processing discrete input signals from various sensors and switches.

**Key Features:**

* **32 Discrete Input Points:** The module provides 32 individual input points for connecting discrete sensors and switches. Each input point can handle a 24 VDC signal and is equipped with filtering and protection circuitry to ensure reliable operation.

* **Positive/Negative Logic Compatibility:** The module supports both positive and negative logic, allowing it to be compatible with a wide range of input devices.

* **Input Filter:** The module features a selectable input filter to eliminate high-frequency noise and interference from the input signals.

* **Single Interrupt Input:** One of the input points can be configured as an interrupt input, allowing the PLC to respond immediately to critical events or changes in the input signal.

* **Compact Design:** The module has a compact design for easy installation in tight spaces.

**Technical Specifications:**

| Parameter | Value |
|—|—|
| Input Points | 32 |
| Input Voltage | 24 VDC |
| Input Current | 10 mA |
| Input Logic | Positive/Negative |
| Input Filter | Selectable |
| Interrupt Input | 1 |
| Power Supply | 24 VDC |
| Operating Temperature Range | -20°C to +60°C (-4°F to 140°F) |
| Storage Temperature Range | -40°C to +85°C (-40°F to 185°F) |
| Dimensions (L x W x H) | 7.9 x 3.1 x 1.5 in (201 x 79 x 38 mm) |
| Weight | 1.3 lb (0.6 kg) |

**Applications:**

The GE IC697MDL653 is commonly used in a variety of industrial automation applications that require monitoring and processing discrete input signals, including:

* **Machine Control:** Monitoring the status of machine sensors, such as limit switches, position sensors, and safety interlocks.

* **Process Control:** Monitoring process parameters, such as temperatures, pressures, and flow rates, using discrete sensors.

* **Conveyor Control:** Monitoring the position and movement of conveyor belts using proximity sensors and photoelectric sensors.

* **Alarm Systems:** Detecting faults, failures, or unauthorized access using discrete sensors and switches.

* **Data Acquisition:** Collecting discrete data from sensors and switches for monitoring and analysis.

**Additional Information:**

* The GE IC697MDL653 is compatible with all Series 90-70 PLCs and programming software.

* The module requires programming using GE Fanuc’s PLC programming software to configure its input parameters and data handling functions.

* For detailed installation, configuration, and programming instructions, refer to the official GE Fanuc IC697MDL653 user manual.

**Please note:** The information provided here is based on publicly available information and may not be entirely accurate. For complete and up-to-date information, please refer to the official GE Fanuc product documentation or contact GE Fanuc customer support.
