FOXBORO FPS400-24

FOXBORO FPS400-24 is a power module designed for industrial automation and process control applications.The following is a detailed introduction to it:

1.Basic features

Brand:FOXBORO

Model:FPS400-24

Type:power module

Application scenarios:industrial automation,process control,power systems,manufacturing,building automation,transportation systems and data centers

2.Technical specifications

Input specifications

FPS400-24 provides two power supply options with different input voltages:

1 20/240 VAC or 125 VDC input(P0922YU)

Input voltage range:85 to 265 VAC or 108 to 145 VDC,125 VDC nominal

Input frequency range:47 to 63 Hz

FOXBORO FPS400-24

Input current:5.6 A(maximum rms)at 85 VAC,2.5 A(maximum rms)at 230 VAC

Efficiency:85%(typical)at 85 VAC,92%(typical)at 120 VAC,230 VAC 90%(typical)at 24 VDC

Inrush current:20 A(peak at cold start at 110 Vac),40 A(peak at cold start at 220 Vac)

24 VDC input(P0922YC)

Input voltage range:18 to 35 VDC,nominal 24 VDC

Input current:19.5 A at 24 VDC input

Efficiency:85%typical at 24 VDC input

Output specifications

Output voltage:24.0 VDC,±0.2 VDC nominal factory setting

Voltage line regulation:Output voltage 2.0%

Voltage load regulation:2.0%of output voltage

Ripple and noise at 20MHz:100mV(peak-to-peak),10mV(maximum effective value)

Temperature coefficient:0.025%/°C

Start-up time(soft start):3 seconds typical,5 seconds maximum at 110V AC input or 24V DC input

III.Functions and features

High efficiency:The sealed power supply has high efficiency,up to 95%for P0922YU and 81%for P0922YC,so it has high reliability and low failure rate.

Wide range input:Supports a wide range of AC and DC input voltages to meet global power supply requirements.

Power factor correction:Improve power utilization efficiency and reduce harmonic interference.

Dual-stage current limiting:Provides additional current protection.

Overvoltage shutdown circuit:Prevents excessive output voltage and protects load equipment.

Transformer isolation:24V DC output for improved safety.

Multiple installation methods:Supports horizontal or vertical DIN rail installation,as well as bracket or wall mounting holes,which is convenient and flexible.

Real-time monitoring:Supports real-time status monitoring,which facilitates timely detection of potential problems and improves system reliability.

FOXBORO FPS400-24

4.Application and compatibility

The FPS400-24 power module can be used to power external field devices and is widely used in process control and monitoring systems such as chemical,petroleum,natural gas,electricity,water treatment and other industries.

It is compatible with a variety of controllers and devices,and is easy to integrate with existing systems.
