The FOXBORO FBM206 is a multifunctional module used in the Foxboro I/A Series System. It is designed to provide multiple functions, including analog input, analog output, digital input, and digital output capabilities.

The module features six analog input channels, which can be used to measure various types of signals, such as temperature, pressure, flow, and level. It also has six analog output channels, which can be used to control devices like valves and actuators.

In addition to the analog channels, the FBM206 module has sixteen digital input channels, which can be used to monitor the status of discrete signals, such as on/off states or alarm conditions. It also has sixteen digital output channels, which can be used to energize or de-energize devices or activate alarms.

The FBM206 module is known for its high-performance and reliability. It is designed to operate in harsh industrial environments and is resistant to temperature, humidity, and electrical noise.

The FOXBORO FBM206 is a Remote I/O Module manufactured by Schneider Electric. It is part of the Foxboro Evo system, which is designed for process automation and control in industrial applications.

Product Information:

• Model: FBM206
• Manufacturer: Schneider Electric
• System: Foxboro Evo
• Communication: RS485 Modbus RTU
• Power Supply: 24 VDC
• Operating Temperature: -40°C to 85°C (-40°F to 185°F)
• Mounting: DIN rail or panel mount
