EMERSON A6500-UM

EMERSON A6500-UM is a high-performance universal measurement card.The following is a detailed introduction to the product:

1.Product Overview

EMERSON A6500-UM universal measurement card is an important component of the AMS 6500 ATG mechanical protection system.It is equipped with 2 sensor input channels(which can be used independently or in combination according to the selected measurement mode)and supports various types of sensors,such as eddy current,piezoelectric(accelerometer or velocimeter),seismic(electrodynamic force),LF(low-frequency bearing vibration),Hall effect and LVDT(need to be used in conjunction with A6500-LC).This measurement card is not only powerful but also easy to integrate,making it an ideal choice for industrial automation and monitoring.

EMERSON A6500-UM

2.Technical specifications and features

Sensor input:supports a variety of sensor types to meet different monitoring needs.

Digital input and output:equipped with 5 digital inputs and 6 digital outputs,convenient for signal interaction with other devices.

Communication interface:The measurement signal is transmitted to the A6500-CC Com card via the internal RS 485 bus and converted to Modbus RTU and Modbus TCP/IP protocols for further transmission to the host or analysis system.

Analog output:The measurement results can be output via 0/4~20mA analog outputs,which have a common ground and are electrically isolated from the system power supply.

Cabinet space requirements:Dual-channel,3U size,1-slot plug-in module,compared with the traditional four-channel 6U card,the cabinet space requirements are reduced by half.

Compliance with standards:Meets API 670 standards,hot-swappable modules for easy maintenance.

Self-test function:Including monitoring hardware,power input,hardware temperature,sensors and cables,etc.,to ensure the stability and reliability of the system.

EMERSON A6500-UM

III.Functions and applications

High-precision measurement:Using high-precision sensors and advanced signal processing technology,it can accurately measure various physical quantities such as shaft vibration,shaft eccentricity,shell piezoelectric vibration,etc.

Intelligent fault diagnosis:Through the analysis and processing of vibration data,potential fault modes can be identified,fault warning and fault diagnosis information can be provided,and users can take corresponding maintenance measures in time.

Multiple monitoring modes:supports multiple monitoring modes such as absolute vibration,relative vibration and key phase signal,which can be selected according to different equipment and application scenarios.

Easy to integrate and configure:With good integrability and configuration flexibility,it can be seamlessly integrated with other industrial automation systems to provide a unified monitoring and management platform.

IV.Application fields

EMERSON A6500-UM universal measurement card is widely used in the following fields:

Petrochemical:used to monitor the shaft vibration,temperature and other parameters of rotating equipment to ensure production safety and stability.

Electricity:monitor the operating conditions of power equipment,such as transformers and generators,to improve the operating efficiency and stability of power equipment.

Mechanical manufacturing:used to monitor the operating conditions of equipment such as machine tools and CNC centers to improve processing accuracy and production efficiency.

Automated production line:monitor the operating conditions of various equipment on the production line to improve the automation and production efficiency of the production line.

Environmental monitoring:monitor the temperature,humidity,pressure,gas concentration and other parameters in the environment to provide accurate data support for environmental protection decisions.
