BENTLY 3500 40M 176449-01

BENTLY 3500/40M 176449-01 is a displacement monitor or front monitor produced by Bently Nevada.The following is a detailed introduction to it:

1.Product Overview

Brand:Bently Nevada

Series:3500 Series

Model:40M Displacement Monitor(176449-01)

BENTLY 3500 40M 176449-01

2.Technical Specifications and Parameters

Input Signal:DC voltage,current(determined when ordering or programmed by configuring the programmer),input impedance current impedance≤160Ω,voltage impedance≥250KΩ,input current/voltage≤30mA/≤7V.

Output Signal:4-20mA,0-10mA,0-20mA,1-5V,0-5V,output load current type≤500Ω,voltage type≥250KΩ(please indicate when ordering if higher load capacity is required).

Communication protocol:MODBUS-RTU protocol,RS-485 transmission distance≤1000 meters.

Power supply:DC24V(±10%),AC100-265V 50-60Hz,power consumption DC24V power consumption≤1.5W,AC100-265V power consumption≤2W.

Other parameters:

Insulation strength:2500Vrms between input/output/power supply(1 minute,no spark).

Operating temperature:0~50℃.

Relative humidity:≤85%RH.

Temperature drift:50ppm.

Installation method:35mmDIN rail installation.

Installation size:22.5×110×115mm(width×height×depth).

Measurement accuracy:0.2%FS±1 word.

Response time:≤1S.

Weight:about 150 grams.

BENTLY 3500 40M 176449-01

III.Product features

Wide measurement capabilities:Able to monitor a variety of physical quantities,including vibration,displacement,etc.,suitable for a variety of different industrial applications.

Advanced monitoring and diagnostic functions:can monitor the operating status of the equipment in real time,detect potential problems in time,and provide detailed fault diagnosis information.

High precision and stability:provide accurate measurement results and reliable control systems to ensure the safe operation of the equipment.

Simple design and easy installation:can be easily connected to various sensors and control systems,easy to install.

Powerful alarm system:trigger alarms according to preset alarm values​​to ensure the safe operation of the equipment.

IV.Application fields

Power industry:in power plants and power stations,used to monitor the operating status of key equipment,such as generators,transformers,bearings,etc.

Oil and gas industry:monitor various key equipment,such as centrifugal compressors,centrifugal pumps,centrifugal fans,etc.

Chemical industry:monitor reactors,centrifuges,agitators and other equipment.

Manufacturing industry:monitor various production equipment,such as machine tools,injection molding machines,die-casting machines,etc.

Other industrial fields:suitable for various industrial fields that require real-time monitoring and fault diagnosis of key mechanical equipment
