BENTLY 3500 15

BENTLY 3500/15 is an AC/DC power supply module developed by Bently Nevada.The following is a detailed introduction to the product:

I.Product Overview

BENTLY 3500/15 is a half-height module that must be installed in the designated slot on the left side of the rack.The main function of this power supply module is to convert the input AC voltage to an acceptable DC voltage,or directly convert the accepted DC voltage to power other 3500 modules.It can accept a wide range of inputs and convert them to the voltage required by the 3500 modules.

II.Product Features

Compatibility:The BENTLY 3500/15 power supply module is compatible with the 3500 series mechanical protection system,but it should be noted that the Legacy 3500 AC power supply,high-voltage AC PIM and low-voltage AC PIM are not compatible with universal AC power supplies and PIMs;similarly,the Legacy 3500 high-voltage and low-voltage DC power supplies and PIMs cannot be used with high-voltage and low-voltage DC power supplies and PIMs.

Redundant design:In the 3500 rack,one or two power supplies of any combination of AC and DC can be accommodated.When two power supplies are installed,the upper power supply acts as the primary power supply and the lower power supply acts as the backup power supply.As long as one power supply is installed,removing or installing the second power supply module will not affect the operation of the rack.

Wide Input Range:This power supply module is able to accept a wide range of input voltages and convert them to voltages that other 3500 modules can accept.

BENTLY 3500 15

III.Technical Specifications

Input Voltage:

AC Input:175 to 264 Vac rms(247 to 373 Vac,pk),47 to 63 Hz;or 85 to 132 Vac rms(120 to 188 Vac,pk),47 to 63 Hz.

DC Input:88 to 140 Vdc;or 20 to 30 Vdc.

Over-Range Protection:For all power supply types,low voltage will not damage the power supply or PIM.However,an over-range voltage will open the fuse on the PIM.

Current:

175 to 254 Vac input:2.3 A rms(max).

85 to 132 Vac input:4.5 A rms(max).

88 to 140 Vdc input:2.5 A(max).

20 to 30 Vdc input:10.0 A(max).

Power OK LED:Lights up when the power supply is working properly.

Operating temperature:-30℃to+65℃(-22 F to+150 F).

Storage temperature:-40℃to+85℃(-40 F to+185 F).

Humidity:95%,non-condensing.

Electromagnetic compatibility(EMC):Complies with many international standards and regulations,such as EN50081-2,EN55011,EN50082-2,etc.

IV.Physical characteristics

Power module size:120.7mm x 50.8mm x 251.5mm(H x W x D).

Power module weight:1.39kg.

Power input module size:120.7mm x 25.4mm x 114.3mm(height x width x depth).

Power input module weight:0.34kg.

BENTLY 3500 15

V.Application fields

BENTLY 3500/15 power modules are commonly used in the following fields:

Rotating equipment monitoring:In conjunction with Bently Nevada’s monitoring system,monitoring parameters such as vibration,axis displacement,temperature,etc.of rotating equipment helps to monitor the health of the equipment in real time,predict potential failures,and improve equipment reliability and availability.

Industrial automation:The various components of the power supply monitoring system ensure the stable operation of the monitoring system.

Power plant operation and maintenance:Monitoring and protecting key equipment such as generators and turbines helps to improve the operating efficiency and reliability of power plants.

Oil and gas industry:Monitoring drilling equipment,pumping stations,compressors and other equipment to ensure the normal power supply of the monitoring system.

Chemical industry:Monitoring and protecting key equipment to ensure the smooth progress of the production process.
