AT-016-1030 SUMTAK

AT-016-1030 SUMTAK

The SUMTAK AT-016-1030 is a type of rotary incremental encoder. It is designed to provide accurate and reliable position and velocity feedback in various industrial and automation applications.

The encoder features a resolution of 1030 pulses per revolution, meaning that it can divide a full 360-degree rotation into 1030 equally spaced positions. This high resolution allows for precise and fine-grained measurements of shaft position or rotary speed.

The AT-016-1030 encoder utilizes a solid and durable construction, ensuring long-term reliability even in demanding environments. It is resistant to dust, moisture, and other common contaminants that can affect performance.

With its compact size and simple installation process, the AT-016-1030 encoder can be easily integrated into existing systems. It supports various output options, such as A/B phase quadrature signals, analog voltage outputs, or digital interface protocols, providing flexibility and compatibility with different control systems.

INDRAMAT Eco Drive DKC03.3-040-7-F​W DKC-03.3-040-7-​FW

ECODRIVE INDRAMAT SERVO DRIVE DKC03.1-040-7-F​W

Indramat permanent Magnet Motor MHD115B-024-NG0​-AN

Servomotor INDRAMAT MAC112C-0–D-3-C NEU-OVP

INDRAMAT TDM-1.2-030-300​-W1-000 TDM1.2-030-300-​W1-000

Indramat Rexroth PPC-R02.2N-N-V2​-NN-NN-FW PPC-R02.2 NEU

For the AT-016-1030 SUMTAK encoder, the parameters are as follows:

1. Resolution: The resolution of the encoder represents the number of signal pulses within each rotation cycle (360 °). The resolution of the AT-016-1030 SUMTAK encoder is 1030.

2. Working voltage: The working voltage of the encoder refers to the voltage range required for normal operation. The working voltage of the AT-016-1030 SUMTAK encoder is generally DC 5V.

3. Output signal type: The output signal type of the encoder can be an analog signal (such as analog voltage or analog current) or a digital signal (such as pulse signal or RS485 communication). The output signal type of the AT-016-1030 SUMTAK encoder is a digital pulse signal.

4. Interface type: The interface type of the encoder determines its communication with other devices. AT-016-1030 SUMTAK encoders generally use standard encoder interfaces, such as A, B, and Z phase digital signal interfaces.

5. Appearance dimensions: The appearance dimensions of the encoder include diameter, height, etc., which determine the installation method and space requirements of the encoder. The appearance dimensions of the AT-016-1030 SUMTAK encoder may vary depending on the specific model.

6. Protection level: The protection level of the encoder refers to its ability to protect against water, dust, vibration, etc. under different environmental conditions. The AT-016-1030 SUMTAK encoder generally has a certain level of protection, such as IP65.

7. Working temperature range: The working temperature range of the encoder refers to the temperature range that can operate normally. The working temperature range of the AT-016-1030 SUMTAK encoder is generally -10 ℃ to 70 ℃.
