AO2020 ABB comprehensive analyzer

Product Description

AO2020 ABB comprehensive analyzer

Function:

Measure and analyze the electrical parameters of the power system

Usage:

Power system monitoring

Power quality analysis

Electricity metering

Fault diagnosis

Features:

High precision:measurement accuracy can reach 0.2%

Multifunctional:can measure parameters such as voltage,current,power,harmonics,frequency,etc

Easy to use:easy to operate,user-friendly interface

Product Description:

AO2020 ABB comprehensive analyzer is a high-precision,multifunctional,and easy-to-use comprehensive analyzer designed specifically for power systems.It has the following characteristics:

High precision:The measurement accuracy can reach 0.2%,which can meet the needs of power system monitoring and analysis

Multifunctional:can measure parameters such as voltage,current,power,harmonics,frequency,etc.,to meet the needs of different users

Easy to use:Easy to operate,user-friendly interface,even for personnel without professional knowledge

Product Description:

The AO2020 ABB comprehensive analyzer adopts a modular design,which is easy to install.It has the following structure:

Measurement module:including measurement circuits for voltage,current,power,etc

Analysis module:including harmonic,frequency,and other analysis circuits

Display module:Display measurement and analysis results

The Advance Optima process gas analyzer adopts a modular design,which can provide long-term safety assurance for your investment.The analyzer module can be freely combined into customized solutions and upgraded or expanded with new features at any time.Remote modules are easy to connect and operate centrally.

The advantages that Advance Optima brings you:

One central unit and up to 4 analyzer modules

-Having common control

-Having a common connection technology

-Located in a common system shell

All analyzers adopt high-performance measurement technology

-Photometer

-In situ laser analyzer

-Oxygen analysis using new micro wing technology

Instrument-Oxygen analyzer

-Trace oxygen analyzer

-Thermal conductivity analyzer

-FID analyzer

Multiple analyzer systems

-Up to four analyzer modules

-Up to six sample components

Extensive automatic calibration

-Use air or integrated calibration unit

-No need to test gas cylinders

Self monitoring function indicates when maintenance is needed

The approved models in hazardous areas comply with international standards,such as

-ATEX

-EAC

-CSA

Product parameters:

Voltage measurement range:10V~600V

Current measurement range:1A~100A

Power measurement range:1kW~100kW

Harmonic measurement range:2-50 times

Frequency measurement range:45Hz~65Hz

Product specifications:

Dimensions:233mm x 102mm x 41mm

Weight:1.2kg

Application field:

AO2020 ABB comprehensive analyzer can be widely used in power plants,substations,distribution networks,industrial and mining enterprises,data centers and other fields.

Here are some specific application examples:

In power plants,it is used to monitor the operation status of generator sets and analyze the quality of electrical energy

In substations,it is used to monitor the operation status of transformers and analyze grid harmonics

In the distribution network,it is used to monitor the operation status of distribution lines and analyze electrical energy losses

In industrial and mining enterprises,it is used to monitor the operation status of production equipment and analyze the quality of electrical energy

In the data center,used to monitor the operation status of servers and analyze power quality
