Allen Bradley 1756-TBCH

The Allen Bradley 1756-TBCH is a removable terminal block(RTB)produced by Allen-Bradley(now a brand of Rockwell Automation)and is mainly used for interconnection of 1756 series I/O modules.The following is a detailed introduction to the product:

1.Basic information

Brand:Allen-Bradley

Model:1756-TBCH

Type:Removable terminal block(RTB)

Purpose:For interconnection and factory wiring of 1756 series I/O modules

Allen Bradley 1756-TBCH

2.Technical specifications

Structure:36-pin cage clamp with standard housing(wire arm depth less than 2.5 square millimeters)

Screw torque:0.5 Nm

Screwdriver width:3.2 mm(1/8 inch)screwdriver is recommended

Dimensions:5.51 x 4.41 x 5.71 inches

Weight:0.3 pounds(0.1 kg)

Current consumption:Backplane current(5 volts)1200 mA,backplane current(24 volts)2.5 mA

Power consumption:3.5 watts(or 6.19 watts,depending on the statement of different sources)

3.Wiring requirements

Wire specifications:For single-wire connections,the wire size must be 0.332.1 square millimeters(2214 AWG);for two-wire connections,the wire size must be 0.331.3 square millimeters(2216 AWG)

Wire type:solid or stranded copper wire rated for 90°C(194°F)or higher

Wiring precautions:Do not connect more than two wires on any single terminal

Allen Bradley 1756-TBCH

Fourth,product features

Flexibility:1756-TBCH provides the flexibility of interconnecting 1756 I/O modules and industrial factory wiring,and can be easily plugged into the front of the I/O module.

Compatibility:It can be installed with a variety of 1756 series I/O modules,such as 1756-IA16I,1756-IA32,1756-IB16D,etc.

Durability:Designed for use in a clean and dry industrial environment with an operating temperature of 0~60°C and an impact force of 30g,it has good durability and reliability.

Five,application areas

Allen Bradley 1756-TBCH is widely used in various industrial automation and control systems,such as manufacturing,energy,transportation and other fields.In these fields,various equipment and processes need to be precisely controlled and monitored to ensure the stability of the production process and product quality.

VI.Suppliers and Prices

This product is provided by multiple suppliers,and the price may vary depending on the supplier,purchase quantity,time,and product batch.It is recommended to purchase through formal channels and carefully check the product model,specifications,and manufacturer information to ensure product quality and after-sales service.

VII.Precautions

Before purchasing and using,please make sure that the product is compatible with your equipment or system.

Please operate and use in accordance with the product manual and safety specifications to avoid possible risks and losses.

For more detailed information or technical support about Allen Bradley 1756-TBCH,please contact Rockwell Automation’s official channels or authorized agents.

In summary,Allen Bradley 1756-TBCH is a powerful,stable,easy-to-install and use removable terminal block suitable for various industrial automation and control system application scenarios.
