ABB TU810V1

ABB TU810V1

The ABB TU810V1 is a universal input/output module that is designed for use in ABB’s Advant Controller 400 series of programmable logic controllers (PLCs). It provides eight channels of analog input and four channels of analog output, with a range of input and output options available to suit a wide range of industrial applications. The TU810V1 module is designed to be easy to install and configure, with a simple plug-and-play design that allows it to be quickly integrated into existing control systems. It also features a range of diagnostic and monitoring tools to help ensure reliable and efficient operation, and is built to withstand harsh industrial environments.

PHOENIX CONTACT IB-ST-24-AI4/BP NSFP IBST24AI4BP

Phoenix Contact IB ST 24 BAO 8/U#2721044-NEW

PHOENIX CONTACT IB-ST-24-AI4/BP USPP IBST24AI4BP

PHOENIX CONTACT 2754312 IB ST 24 AO 4/SF

PHOENIX CONTACT 2754309 IB ST 24 AI 4/SF

PHOENIX CONTACT IB ST 24 CNT MODULE IBST24CNT

PHOENIX CONTACT IB ST 24 DIO 8/8/3-2A NEW

The ABB TU810V1 is a universal input/output module designed for use in ABB’s Advant Controller 400 series of programmable logic controllers (PLCs). It provides 8 channels of analog input and 4 channels of analog output, with a range of configurable input and output types.

Some of the key parameters of the TU810V1 module include:

• Input voltage range: -10V to +10V, 0V to +10V, 0V to +5V, 0mA to 20mA, 4mA to 20mA, thermocouple, RTD, resistance, frequency, and pulse
• Output voltage range: 0V to +10V, 0mA to 20mA, 4mA to 20mA, and pulse
• Input resolution: 16 bits
• Output resolution: 12 bits
• Isolation: 500V AC between channels and between channels and power supply
• Power supply: 24V DC +/- 20%
• Operating temperature range: -40°C to +70°C
• Dimensions: 12.5mm x 119mm x 110mm (W x H x D)
• Weight: 0.2kg

Overall, the TU810V1 module is a versatile and reliable solution for integrating analog signals into an Advant Controller 400 PLC system.
