ABB SPAM150C

ABB SPAM150C is a motor protection relay that integrates a large number of protection functions to provide perfect protection for AC motors of various purposes and prevent motors from being damaged by various electrical faults.The following is a detailed introduction to ABB SPAM150C:

1.Product Overview

Brand:ABB

Model:SPAM150C

Type:General combination relay,designed for AC motors

ABB SPAM150C

2.Protection Function

Thermal overload protection:protects the motor from short-term and long-term overload.The maximum allowable continuous load depends on the setting value,which is usually taken as the rated full load current(FLC)of the motor at an ambient temperature of 40°C.When the motor current increases to a certain value(such as 1.05 times FLC),the thermal overload unit will start and act after a certain delay.

Short-term overload protection:mainly occurs during the starting process of the motor,allowing the motor to start twice under cold conditions and once under hot conditions.According to the starting time of the motor,the setting value that determines the characteristics of the thermal overload unit can be obtained.

Thermal overload pre-alarm:A warning is issued when the motor is just overloaded,reminding the operator to reduce the load of the motor and avoid unnecessary thermal overload tripping.The pre-alarm signal setting value can be set individually as a percentage of the thermal overload trip value.

High-set overcurrent protection(current quick break):Used to protect short circuits between motor windings and phase-to-phase short circuits of feeder cables.Its current setting value can be set to automatically double during startup,usually as low as 0.75 times the motor starting current.

Non-directional ground fault protection:In a system with direct neutral grounding or low impedance grounding,ground faults in motor and feeder circuits can be detected.

Phase imbalance protection:Monitors the imbalance of system current to prevent motor damage due to severe system imbalance or single-phase operation.

Reverse phase protection:When the phase sequence is wrong,the unit will operate with a fixed delay(such as 600ms).

Low current protection:Used for load loss protection of motors,especially suitable for equipment cooled by liquid constant flow,such as submersible pumps,etc.

3.Other functions

Start time accumulator:used to control the number of starts within a certain period of time,which can be set according to the number of allowed starts provided by the motor manufacturer.

Serial communication interface:enables all measurements and register parameters to be transmitted to the control room or other places in the most convenient way.

ABB SPAM150C

4.Product features

Provide a complete set of protection functions to prevent motor damage due to electrical faults.

Applicable to AC motors of various uses,and also to other equipment requiring thermal overload protection,such as cables or power transformer feeders.

Using advanced digital signal processing and communication technology,it can monitor the operating status of the motor in real time.

According to different fault types and operating conditions,the protection parameters can be automatically adjusted to improve the sensitivity and response speed to faults.
