ABB-SPAD346C3

ABB-SPAD346C3 is a relay module or sensor module produced by ABB.The following is a detailed introduction to it:

1.Product Overview

The ABB-SPAD346C3 module integrates multiple protection functions,including overcurrent protection,overvoltage protection,undervoltage protection and overload protection,etc.,to ensure that the power system can be protected promptly and effectively under various faults and abnormal conditions.At the same time,the module has high-precision measurement and communication interface functions,making it an ideal choice for intelligent power systems.

2.Technical Features

Protection function:

Integrates multiple protection functions such as overcurrent,overvoltage,undervoltage and overload protection to ensure the safe operation of the power system.

High-precision measurement:

ABB-SPAD346C3

Equipped with high-precision sensors and measurement circuits,it can accurately measure various physical quantities in the power system,such as current,voltage,etc.

Fast response:

With the characteristics of fast response,it can quickly detect abnormal conditions in the power system and take protective measures immediately.

Flexible configuration:

Provides flexible configuration options,and users can adjust and set different protection parameters according to actual needs to adapt to different power systems and application scenarios.

Communication interface:

Usually equipped with a communication interface,such as Modbus,Profibus or Ethernet,etc.,which can exchange and communicate data with the host computer or monitoring system to achieve remote monitoring and management functions.

Automatic calibration:

It has an automatic calibration function to ensure the accuracy and stability of the measurement.

Data recording and storage:

It has a data recording and storage function,which can archive historical data for subsequent analysis and review.

3.Technical indicators

Indication accuracy:±0.5%

Recording accuracy:±1%

Control accuracy:±0.5%

Setting range:0~100

Moving time:≤5 seconds

Output contact capacity:

AC:220V 1A(AC non-inductive load)

DC:28V 2A(pure resistance load)

Working environment:

Temperature:0~50℃

Relative humidity:≤90%

Power supply voltage:220V±10%,50Hz±5%

Power consumption:≤20VA

Dimensions:280×288×200 mm(specific dimensions may vary depending on product model or production batch)

4.Application areas

ABB-SPAD346C3 module is widely used in various power systems,such as substations,power plants,distribution systems,etc.It can provide reliable protection and guarantee for the safe operation of power equipment and systems,and ensure the stable operation of the power system.At the same time,its high-precision measurement and communication interface functions also enable it to play an important role in intelligent power systems.

ABB-SPAD346C3

5.Precautions

When using this product,please read the product manual and installation guide carefully to ensure correct installation and configuration.

During use,please keep the working environment clean and dry to prevent water,oil and other liquids from entering the relay module.

Check the working status of the relay module regularly.If any abnormality is found,please contact a professional for repair or replacement.

In summary,ABB-SPAD346C3 is a powerful and stable relay module or sensor module that can meet various control and monitoring needs in the power system.
