ABB CI810B

ABB CI810B

The ABB CI810B is a communication interface module designed for use in industrial automation and control systems. It is part of ABB’s Control System AC 800M series, which is commonly used in various industries for process control and automation applications.

Here is a brief description of the ABB CI810B:

1. Communication Interface: The CI810B serves as a communication interface between the ABB Control System AC 800M and various field devices, including sensors, actuators, and other control equipment. It enables the exchange of data between the control system and these devices.
2. Compatibility: This module is compatible with the ABB Control System AC 800M, making it an integral part of the system’s architecture.
3. Communication Protocols: The CI810B supports various communication protocols, which may include but are not limited to, PROFIBUS DP, MODBUS RTU, and IEC 60870-5-101/104. The specific protocols supported can vary based on the configuration and firmware version.
4. Diagnostics and Monitoring: The module typically provides diagnostic features that help monitor the health and status of the communication network, making it easier to identify and resolve issues.
5. Redundancy Options: Depending on the application and requirements, the CI810B may offer redundancy options to ensure high availability and reliability of the communication network.
6. Configuration: Configuration of the CI810B is done through the engineering tools provided by ABB. Engineers and operators can set up parameters and configure the module to work with the desired communication protocol and network topology.
7. Industrial Applications: The ABB CI810B is commonly used in industries such as manufacturing, utilities, and process control, where reliable communication between the control system and field devices is essential for automation and process monitoring.

Volvo VME L480 Wheel Loader Parts Manual Microfiche

Volvo VME L480T Wheel Loader Parts Manual Microfiche

CMC Ethernet Node Processor 320001-04 ENP-10 VME REV-D

MUPAC VME Slot Bypass 6U,NEW

Volvo VME F666 Log Skidder Parts Manual Microfiche

Volvo VME F667 Log Skidder Parts Manual Microfiche

Volvo VME F668 Log Skidder Parts Manual Microfiche

Volvo VME Parts Manual A35 Artic Hauler Microfiche

The ABB CI810B is a communication interface module that is part of the Compact Control Builder AC 800M controller system. It is designed to provide connectivity between different devices and systems within an automation control system.

Here are some key features and parameters of the ABB CI810B:

• Communication Protocol: The CI810B supports various communication protocols such as Modbus RTU, Modbus TCP/IP, IEC 60870-5-101, and IEC 60870-5-103.
• Connectivity: It offers multiple communication channels, including Serial RS-232/RS-485 and Ethernet.
• Data Exchange: The module allows for data exchange between the AC 800M controller and other devices/systems in the network.
• Flexible Configuration: The CI810B can be configured using ABB’s engineering tools, such as Control Builder M or 800xA.
• Diagnostics: It provides detailed diagnostic information for troubleshooting and maintenance purposes.
• Redundancy: The CI810B can be used in a redundant configuration, ensuring high availability and system reliability.
• Operating Conditions: The module can operate in a wide temperature range, typically -25°C to +60°C, and in various environmental conditions.
