ABB 216AB61

ABB 216AB61

The ABB 216AB61 is a solid-state relay that is designed to switch AC loads up to 600V and 25A. It is a single-phase relay that operates on a control voltage of 24-280V AC/DC.

Some of the key features of the ABB 216AB61 include:

• Zero-crossing switching for reduced EMI and longer relay life
• LED status indicator for easy monitoring of relay operation
• Built-in overvoltage protection for added safety
• DIN rail mounting for easy installation

NEW SIEMENS 6SE6400-2FB00 MICROMASTER 4 EMC FILTER

NEW KIDDE XV CONTROL SYSTEM VALVE ACTUATOR 120042-001

QTY 6 175W ED17 CLEAR METAL HALIDE BULBS MP175/U/MED

9 OSRAM 1000W HALOGEN G9.5 DISPLAY/OPTIC LAMPS/BULBS

1969 JIM BEAM LAS VEGAS/HOOVER DAM DECANTER SEALED

Enlarge

AO SMITH CONDENSER FAN MOTOR 1/5 HP ARMSTRONG LENNOX

QTY 10 NEW SENTRION HVAC LOW PRESSURE SWITCH ILPS-018

The ABB 216AB61 also has a number of technical parameters that are important to consider when selecting and using the relay. These include:

• Rated control voltage: 24-280V AC/DC
• Rated operational current: 25A
• Maximum switching voltage: 600V AC
• Minimum switching current: 100mA
• Maximum off-state leakage current: 1mA
• Maximum on-state voltage drop: 1.6V
• Operating temperature range: -40°C to +80°C

Overall, the ABB 216AB61 is a reliable and versatile solid-state relay that is suitable for a wide range of industrial and commercial applications.
