AB 1746-IB16

AB 1746-IB16

The AB 1746-IB16 is a digital input module manufactured by Allen-Bradley. It is part of the SLC 500 series and is designed to be used with a programmable logic controller (PLC) system. The module has 16 inputs that can be used to monitor the status of digital signals from various devices such as switches, sensors, and other control devices. The inputs are isolated from each other and from the system ground, providing protection against electrical noise and interference. The module is easy to install and configure, and can be used in a wide range of industrial applications.

AB 1746-IB16 is a 16 channel digital input module that can be used to input external digital signals into PLC systems.The following are the instructions,parameters,and usage methods of the product:

Product Description:

-16 digital input channels

-Input voltage range:10-30V DC

-Input type:DC input

-Input signal status:ON/OFF

-Suitable for Allen Bradley SLC 500 series PLC system

Product parameters:

-Input voltage range:10-30V DC

-Input current:maximum 8mA

-Input signal status:ON/OFF

-Input filtering time:5ms

-Working temperature range:0-60℃

-Storage temperature range:-40-85℃

-Relative humidity:5-95%,no condensation

Usage:

1.Insert the module into the I/O slot of the PLC system.

2.Connect external digital signals to the input terminals of the module.

3.Configure the input channels of the module in the PLC program to read external digital signals.

4.Use the read digital signals in the program for control or monitoring.

Precautions:

When connecting external digital signals,attention should be paid to the input voltage range and input type to avoid damaging the module or PLC system.

When using the module,attention should be paid to the operating temperature range and relative humidity to ensure the normal operation of the module.

When configuring the input channels of the module,attention should be paid to the channel number and corresponding input terminals to avoid reading incorrect digital signals.
