140CPU67160C SCHNEIDER Hot Spare Processor

Product Description

140CPU67160C SCHNEIDER Hot Spare Processor

Function:Provides redundant processing capability in dual machine hot backup systems,improving system reliability

Usage:Widely used in the field of industrial automation control,such as:

Manufacturing industry

Energy

Transportation

Architecture

Agriculture

Features:

Supports dual machine hot backup

Automatic Failover

High reliability

Scalability

Easy to maintain

Product Description:

The 140CPU67160C hot backup processor is a high-performance and highly reliable redundant processing module designed specifically for the Modicon Quantum series PLC.It supports dual machine hot backup and can automatically detect and switch faulty processors to ensure continuous system operation.

Connectivity and Networking

140CPU67160C is equipped with multiple connectors,including RJ45 connectors for Ethernet and Modbus network connections,as well as SUB-D 9 female connectors for Modbus Plus network connections,which help seamlessly integrate into various industrial networks.Its support for various communication protocols ensures compatibility and interoperability with various devices and systems.

Performance and specifications

The clock frequency of 140CPU67160C is 266 MHz,providing the processing power required for efficient processing of complex tasks.It provides flexibility in system configuration,supports up to 10 slots,and can accommodate various expansion modules and peripherals to meet specific application requirements.

I/O processing and expansion

This CPU has impressive I/O processing capabilities,supporting up to 8000 inputs and 8000 outputs in distributed configurations for each network,and 31744 inputs and outputs in remote settings.It supports application specific I/O(such as precise timestamps and high-speed interrupt inputs)to meet a wide range of industrial automation needs.

Memory and storage

140CPU67160C has 1024 kB of internal RAM,up to 8 MB of expandable memory(used for file storage through PCMCIA cards),and up to 7168 kB of program storage,providing sufficient memory resources for the data and programs required for storage system operations.

Execution time and efficiency

The execution time of floating-point operations is as low as 0.4 to 0.5µs,and the execution time of Boolean and fixed-point operations is as low as 0.045 to 0.06µs.The CPU ensures fast and efficient processing of instructions,thereby improving overall system performance and responsiveness.

System monitoring and diagnosis

The CPU is equipped with LED indicators for Ethernet conflicts and activities,which provide visual prompts for system status and network communication,thereby facilitating troubleshooting and maintenance tasks.

The 140CPU67160C hot backup processor adopts a modular design,which is easy to install and maintain.It has the following main components:

CPU processor

Memory

Communication interface

I/O interface

Product parameters:

CPU model PowerPC 604e

Main frequency 400 MHz

Memory 1 MB

Two multi-mode fiber optic Ethernet communication interfaces

I/O interface 2 RS-232/422/485 interfaces

Scalability supports up to 8 expansion modules

Installation method Backboard/rack

Working temperature 32…+140°F/0…+60°C

Product specifications:

Size:105 x 70 x 40 mm Weight:0.65 kg

Application field:

The 140CPU67160C hot backup processor is widely used in the field of industrial automation control,such as:

Manufacturing industry:automobiles,electronics,machinery,textiles,etc

Energy:power generation,transmission and distribution,new energy,etc

Transportation:rail transit,aerospace,ships,etc

Architecture:intelligent buildings,building automation,etc

Agriculture:Agricultural machinery,irrigation systems,etc
