Product Parameters (产品参数)

• Model: 8502-BI-DP
• Input Voltage: 24VDC
• Maximum Load Current: 2A
• Communication Protocol: PROFIBUS DP
• Operating Temperature: -20°C to +60°C
• Protection Class: IP20

Specifications (规格)

• Manufacturer: GE Automation
• Type: Bus Interface Module (BIM)
• Function: Connects GE 8000 Series I/O modules to a PROFIBUS DP host
• Data Transmission Rate: Up to 6 Mbaud

Dimensions and Weight (尺寸和重量)

• Dimensions: 45mm x 100mm x 115mm¹
• Weight: Approximately 300g¹

Series (系列)

• Part of GE’s automation and control systems, specifically designed to interface with the GE 8000 Series I/O modules.

Features (特征)

• High-Speed Data Acquisition: Enables high-speed data acquisition from I/O modules, with LAN operation speed up to 6 Mbaud².
• PROFIBUS DP Slave Device: Acts as a slave device to the PROFIBUS DP master, allowing seamless integration into PROFIBUS networks².
• Supports Cyclic and Acyclic Data Exchange: Enables both cyclic and acyclic data exchange, meeting various data communication requirements².
• Diagnostics and Special Function Blocks: Supports PROFIBUS extended status information diagnostics and many realized special function blocks².
• High Reliability and Durability: Designed with high-quality materials and manufacturing processes, capable of withstanding harsh industrial environments³.
• Programmable Functionality: Allows for programming of different control logic and algorithms to meet specific application requirements³.

Functions and Applications (作用和应用)

• Data Communication and Control: Serves as a critical component in industrial automation systems, enabling data communication and control between GE 8000 Series I/O modules and PROFIBUS DP hosts².
• Multiple Industries: Can be used in a variety of industries and applications, including discrete manufacturing, process control, machine control, and building automation².
• System Integration: Facilitates system integration by providing a standard interface between different devices and systems, simplifying network architecture and reducing complexity⁴.

Please note that the information provided is based on the available search results and may be subject to change. Always refer to the latest technical documentation or contact the manufacturer for the most accurate and up-to-date information.
