EATON XVS-440-10MPI-1-1U is an industrial automation device launched by EATON.It combines servo drive and touch screen control functions and is suitable for automation control needs in multiple scenarios.The following is a detailed analysis of information from various sources:

1.Product Overview

XVS-440-10MPI-1-1U is a high-performance servo drive with an integrated 10.4-inch color touch screen that supports multiple control modes and communication protocols.Its design focuses on low power consumption,high precision and ease of use,and is widely used in mechanical manufacturing,automated production lines and other fields.

2.Core functions and technical parameters

(1)Servo drive characteristics

Control mode:Based on 32-bit DSP digital control,it supports three modes:position control,speed control and periodic position control,with fast response speed and high positioning accuracy.

Output capacity:The maximum output current is 3A/phase,and the overload capacity is 3 times,which is suitable for heavy-load scenarios.

Communication interface:Built-in CAN bus,supports standard CANopen protocol,and can mount up to 127 devices,which is convenient for multi-axis system networking.

Encoder compatibility:supports 20BIT or 17BIT resolution encoders(standard 2500 lines),pulse input frequency can reach 4MPPS,speed frequency response up to 1200Hz.

(2)Touch screen characteristics

Display performance:10.4-inch TFT color screen,resolution 640×480,support 65536 or 256 color display,contrast 350:1,brightness 350 cd/m²,backlight life up to 50,000 hours.

Operation mode:infrared touch screen technology,support gesture operation and icon interface,simplify user interaction.

Input interface:provides 2-way opto-isolated programmable input,supports pulse/direction and orthogonal signal input(up to 100 kHz).

(3)Power supply and expansion

Built-in power supply:integrated 24V power module,internal 1.2kΩresistor,simplifies the string resistance configuration of the host computer position command,and improves the convenience of on-site application.

Modular design:supports automatic identification and expansion of I/O modules,compatible with analog input/output modules(16-bit resolution),suitable for complex control requirements.
