Product Name: ABB 5SHY3545L0014 Low Voltage Circuit Breaker

Manufacturer: ABB

Product Type: Low Voltage Circuit Breaker

Product Description:

The ABB 5SHY3545L0014 Low Voltage Circuit Breaker is a crucial component in electrical distribution systems, providing protection against overcurrent faults and short circuits. It serves as an automatic switching device that interrupts the flow of current when it exceeds a predetermined safe limit, safeguarding electrical equipment and personnel from potential damage and hazards.

Key Features:

• Overcurrent Protection: Protects against overcurrent conditions that could lead to overheating, wire damage, and fire hazards
• Short Circuit Protection: Disconnects the circuit during short circuits, preventing catastrophic damage to equipment and preventing electrical arcs and explosions
• Adjustable Trip Settings: Allows for setting the trip current and time delay to match specific circuit requirements and protection needs
• Compact Design: Offers a compact design for space-saving installation in control panels and switchboards
• Reliable Operation: Ensures reliable operation with high breaking capacity and long service life

Specifications:

• Voltage Rating: 400 V AC
• Current Rating: 35 A
• Breaking Capacity: 14 kA
• Trip Characteristics: Thermal-magnetic
• Trip Settings: Adjustable current and time delay
• Number of Poles: 3 poles
• Mounting Type: DIN rail mount
• Operating Temperature: -25°C to +55°C (-13°F to +131°F)
• Protection Rating: IP40
• Dimensions: Approximately 85 x 75 x 48 mm (3.35 x 2.95 x 1.89 in)
• Weight: Approximately 0.4 kg (0.88 lb)

Applications:

• Protecting Electrical Circuits: Safeguarding electrical circuits in various applications, including residential, commercial, and industrial buildings
• Feeder Protection: Protecting feeder lines that supply power to distribution panels and branch circuits
• Motor Protection: Protecting electric motors from overcurrent and short circuit faults
• Machine Protection: Safeguarding industrial machinery and equipment from electrical faults
• Generator Protection: Protecting generators from overcurrent and short circuit conditions

Overall, the ABB 5SHY3545L0014 Low Voltage Circuit Breaker plays a vital role in ensuring electrical safety and protecting valuable equipment by effectively interrupting overcurrent faults and short circuits.

Please note that the specific applications and ratings of the circuit breaker may vary depending on the electrical system configuration and the specific protection requirements. It is crucial to consult with a qualified electrician to ensure proper selection and installation of the circuit breaker.
