The ABB 5SHY3545L0009 3BHB013085R0001 3BHE009681R0101 GVC750BE101 is an Integrated Gate Commutated Thyristor (IGCT) module manufactured by ABB, a leading global technology company specializing in power and automation solutions. IGCTs are semiconductor devices that combine the advantages of both silicon-controlled rectifiers (SCRs) and gate turn-off thyristors (GTOs), making them suitable for high-voltage, high-power switching applications.

Specifications

• Manufacturer: ABB
• Product Type: Integrated Gate Commutated Thyristor (IGCT) Module
• Model: 5SHY3545L0009 3BHB013085R0001 3BHE009681R0101 GVC750BE101
• Series: GVC750
• Voltage Rating: 3500 V
• Current Rating: 500 A
• Switching Frequency: Up to 2 kHz
• Cooling Method: Forced air or water
• Dimensions: 210 mm x 160 mm x 67 mm (8.27 in x 6.30 in x 2.64 in)
• Weight: 6.5 kg (14.3 lbs)

Features

• High efficiency: IGCTs offer high efficiency compared to traditional SCRs and GTOs, resulting in lower energy losses and reduced operating costs.
• Fast switching speed: IGCTs can switch on and off very quickly, making them suitable for high-speed applications.
• Low switching losses: IGCTs have low switching losses compared to SCRs and GTOs, which contributes to their high efficiency.
• Rugged construction: IGCTs are rugged devices that can withstand harsh operating conditions.

•

  ABB 5SHY3545L0009 3BHB013085

Applications

ABB 5SHY3545L0009 3BHB013085R0001 3BHE009681R0101 GVC750BE101 IGCT modules are commonly used in a variety of applications, including:

• AC Drives: IGCTs are used in AC drives to control the speed and torque of electric motors.
• Renewable Energy: IGCTs are used in renewable energy applications such as wind turbines and solar inverters.
• Power Transmission: IGCTs are used in high-voltage direct current (HVDC) transmission systems.
• Rail Traction: IGCTs are used in rail traction systems to control the speed and power of locomotives.

Additional Information

For more information on the ABB 5SHY3545L0009 3BHB013085R0001 3BHE009681R0101 GVC750BE101 IGCT module, please refer to the following resources:

• ABB IGCT Module Datasheet: https://library.e.abb.com/public/d627aeaa2f9f8b24c1256f4100480fa0/PT_IGCT.pdf
• ABB Power Electronics Website: https://new.abb.com/power-electronics
