Product Model:
5SHX1445H0001 (IGCT Module)
3BHL000391P0101 (IGCT Driver Board)
3BHB003230R0101 (Heat Sink Component)

Product Parameters:
For the IGCT Module (5SHX1445H0001):

• Rated Voltage: 3300V AC¹
• Rated Current: 1400A¹

•

  -5SHX1445H0001-3BHL000391P0101-3BHB003230R0101-5SXE05-0152-(2)

• Peak Forward Current: 2200A⁵
• On-state Voltage Drop: 2.5V¹
• Gate Trigger Current: 0.5A¹
• Operating Temperature: -40°C to +85°C¹
• Storage Temperature: -40°C to +125°C¹

For the IGCT Driver Board (3BHL000391P0101) and Heat Sink Component (3BHB003230R0101), exact parameters are not provided in the search results.

Product Specifications:

• IP65 Protection Class (Dustproof, Waterproof, and Protection Against Other Contaminants)²
• Modular Design (Easy to Install and Maintain)³
• Size and weight may vary depending on the specific design and configuration²

Dimensions:

• IGCT Module (5SHX1445H0001): 285mm x 220mm x 100mm¹
• Driver Board and Heat Sink dimensions are not provided.

Weight:

• IGCT Module (5SHX1445H0001): 8.5kg¹
• Driver Board and Heat Sink weights are not provided.

Features:

• High Current and Voltage Ratings for Demanding Power Conversion Tasks²
• Compact Design for Space-Saving Installation in Narrow Control Cabinets²
• Advanced Gate Drive Technology for Precise and Reliable Switching²
• Low On-state Voltage Drop to Minimize Power Loss and Improve Efficiency²
• Temperature Monitoring (Some Models)³
• Modular Design for Easy Installation and Maintenance³
• Over-current and Over-voltage Protection³

Functions:

• Switching and Control of AC Power in Industrial Applications²
• Providing Necessary Gate Drive Signals to Precisely Control the IGCT’s Switching (Driver Board)²
• Effective Heat Dissipation to Ensure Reliable and Long-lasting Performance (Heat Sink)²

Application Areas:

• High-power Applications Requiring High Voltage and Current Capabilities²
• Power Converters, Power Electronic Devices, Frequency Converters, etc.³

Please note that the specifications provided are based on the search results and may not be comprehensive. For the most accurate and up-to-date information, it is recommended to consult the official ABB product documentation or contact ABB’s technical support team.
